APP Wireless KL-F 0-120V DC Battery Tester Coulomb Meter
Product information download link KG-FseriesUser Manual http://68.168.132.244/KL-F_EN_manual.pdf Android phone App link http://68.168.132.244/app/KL/KL.apk IOS mobile App link Search Store for "KL Series" Operation demonstration video https://www.youtube.com/channel/UC2jIo4QgMdVootSBaIZNNlw/videos Steps to connect the mobile phone APP to Bluetooth: Open the mobile phone positioning; Open the mobile phone Bluetooth; Open the mobile phone APP, click search, and selectGxxx to automatically connect succefully; No pairing paword is required, and no special pairing is required in the Bluetooth settings; On April 1, 2022, Firmware update content: Low -capacity reminder has been added to the mobile APP ; Low temperature protection has been added to the mobile APP (relays are required for this function); The temperature can be switched to display Fahrenheit or Celsius; TheElectricity consumption (kW.h) only calculates the power consumed during charging; Elapsed AHvalue (Ah) only calculates the capacity released during discharge; The scale range of the voltage and current instrument panel in the mobile phone APP can be set freely, and the scale value of the voltage and current curve also changes accordingly; The KL-F series volt-ampere meter is a new type of coulomb meter that can measure various physical such as voltage, current, power, charge and discharge capacity, watt-hours, and time. At the same time, it can also set to achieve over-voltage protection, under-voltage protection, Multiple protection functions such as over current protection, over power protection, and over temperature protection. The meter can automatically identify the direction of the current, and can monitor the battery capacity in real time, can view the measured data through Bluetooth, and can control the meter and firmware upgrade through the mobile phone APP. ►The product automatically recognizes and detects the current in both charging and discharging directions. When charging, the color of the current is green; when discharging, the color of the current is blue. ►Suitable for a variety of batteries: ternary lithium batteries, lead-acid batteries, lithium phosphate batteries, etc., as long as the battery is within the voltage measuring range. ►The shunt and screws are made of pure copper material, which has good electrical conductivity, low heat generation, and low power consumption. In the standby state, it will not consume too much battery power. ►Support Bluetooth connection mobile phone APP control, ar downloading and installing the APP, through the built-in Bluetooth connection, and all functions can be set through the mobile phone APP. ►The product can be set with over-voltage, under-voltage, over-current, over-power, and external over-temperature protection. When the value is out of the protection value range, the output state of the instrument is turned off (need to be used with a relay) to prevent damage to the electrical equipment. The protection recovery time and delay time can be set, which is suitable for various ocns. ►The product has added a self-calibration function, and the current and capacity values can still remain accurate ar long-time work. ►Amp-hour, watt-hour, and time data can be cleared during the measurement proce without affecting the measurement. The voltage and current values can also be fine-tuned to ensure accurate capacity. ►The product can be upgraded through the online firmware of the mobile phone, which increases the guarantee for the operation of the product. ►The product can accurately measure such as voltage, current, battery capacity, power, power consumption, ambient temperature, battery life, charging time, and batteryulative capacity. Model K L 110F K L 140F K L 160F Sampling method Shunt Shunt Shunt Voltage measurement range(External power supply) 0- 120 V 0- 120 V 0- 120 V Voltage measurement range(Self-powered) 10-80V 10-80V 10-80V Voltage resolution 0.01V 0.01V 0.01V Current measurement range 0~100A 0~400A 0~600A Current resolution 0.01A 0.1A 0.1A Relay optional Temperature measurement range -20-120℃ Capacity display range 0%~100% Power measurement range 0~ 72 KW Power resolution 0.01W AHmeasurement range 0~9999.99AH Capacityresolution 0.001AH Watt-hour measurement range 0~9999.99kWH Watt-hour accuracy 0.001WH Time measurement range 0~999:59:59S Timeresolution 1second Bluetooth communication distance 10m Voltageaccuracy ±2%+3characters Currentaccuracy ±5%+10characters Sampling rate 1 time /second Measuring module power consumption About0.4W Over power protection 0-99999.99W Negative overcurrent protection 0~100A/400A/600A Forward overcurrent protection 0~100A/400A/600A Overvoltage protection 0~1 2 0V Undervoltage protection 0~1 20 V External over temperature protection 0-120℃ Protection recovery time 0-99s Enter standby time 0-60s Delay time setting 0-99S Mailing addre There are 99 P01-P99, P00 is the broadcast addre The interface cool function is powerful to use mobile app, can operate remotely, support data recording and export, convenient and quick. Mobile app supports curve display, real-time curve and history curve of voltage and current, and historical data export. ►Over voltage, under voltage, over current, over power and external over temperature protection can be set,When the value is not in the range of protection value,the output state of the meter is turned off (cooperation is required) The relay is used to prevent the electrical equipment from being damaged. ►The protection recovery time and delay time can be set, which is suitable for various ocns. OVP Over Voltage Protection OTP Over Temperature Protection P Low Voltage Protection OPP Over Power Protection OCP Over Current Protection NCP Negative Over Current Protection 1> Battery Monitor*1 4> Temperature r*1 2> Sampler*1 5> Terminal* 1 3>4P Connection Cable*1 6> 3P Connection Cable*1 About shippingShipping and Packaging All it will be double checked and well packed before sending.It will be dispatched within 2 business days ar buyers pay for the order. It usually takes about 14 to 18 working days for delivering the package to the destination(for remote areas,it may take a little longer). Special Announcement:Please fill in the correct and detailed consignee, address and phone number in the order. For fast and correct delivery.If you do not receive order within 30 working days,please feel free to contact Customer Service before leaving Negative and Neutral Feedback, we will do our best to help you resolve the problem.TaxNo, you will only pay what is quoted as total cost at checkout, no more. You are not expected to pay any additional duties ores. If you are asked by Customs or our logistic partner to pay duties, please contact our Customer Service .Your 100% satisfaction is very ant to usIf the product is not on good condition, You can return this product within 14 working days, please contact customer service center before returning.FeedbackYour satisfaction is our first priorityIf you receive the order and it is in good condition,we would be grateful if you would leave us 5 star Positive Feedback for the transaction.Key FeaturesModel Number:KL-FType:Vehicle Battery TesterDIY Supplies:ELECTRICALOrigin:Mainland ChinaCertification:NONEWhat's In the Box1X APP Wireless KL-F 0-120V DC Battery Tester Coulomb Meter Capacity Monitor 100A 400A 600A Voltage Meter Voltmeter Coulometer
