• The product is mainly used for domestic living water supply,
pipeline pressurization, garden irrigation, vegetable
greenhouse watering, aquaculture, industrial and mining,
enterprises and engineering construction water supply and
drainage.
• Pump clean water, low-viscosity or non-erosive liquids.
• Do not pump flammable, explosive, vaporizable, or contain
no solid particles or tibers liquids
• PH value must be between 6.5-8.5.
• Ambient temperature -15°C ~ + 40°C
• Liquid temperature 0 ~ +60°C
• PH value of liquid: 6.5 ~ 8.5
• The volume ratio of solid impurities in the
liquid: < 0.1%, the particle size :< 0.2 mm
• The voltage fluctuation range ‡ 10% of the
rated value.
Model: Porsini 3013 (60Hz)
Qmax 105 1/min
Output Power: 0.75 kW 1.0 HP Input Power: 1.1 kW
1.5 HP Hmax 33 m In7A IP 54
Suct. Hmax 8 m
a 20 uF 450 VL
Size: 1" x 1"
I.C.L. F
La 35°C
1-Mot
V220~
Continuous duty
Hz 60
3450 min-1
Thermal protector
made in italy 1 Horsepower
