Description :
VC97 Auto Range Digital Multimeter Capacitance Resistance Tester
Features :
Model : VC97
New type , streamline design.
Strong antimagnetic and performance.
Large LCD makes the reading clearly.
Full function protection.
Unit symbol display, very easy to reading.
Relative value, frequency/duty cycle measuring, data hold.
Specification :
Meter size : 185 x 90 x 35mm
Basic function
Range
Basic accuracy
DCV
400mV/4V/40V/400V/1000V
(0.5%+4)
ACV
4V/40V/400V/1000V
(0.8%+6)
DCA
400uA/4000uA/40mA/400mA/20A
(1.0%+5)
ACA
400uA/4000uA/40mA/400mA/20A
(1.5%+5)
Resistance
400/4k/40k/400k/4M/40M
(0.8%+1)
Capacitance
4nF/40nF/ 400nF/4F/40F/200F
(3.5%+8)
Frequency
100Hz/1kHz/10kHz/100kHz/1MHz/30MHz
(0.5%+4)
Centigrade temperature
-40C~1000℃ (can be converted toF)
(0.8%+4)
Special function
VC97
Diode
hFE
Continuity
Approx. less than 3010
Low indication
Approx less than 2.4V
Duty cycle measuring
Data hold
Auto off
Approx.15minutes
Function protect
Input impendence
10M
Sampling rate
3times/s
AC frequency response
40-400Hz
Operation way
Manual or auto range
. display
4000
LCD size
65x41mm
3V AAAx2
dissipation
Quiescent current approx. 2mA
Package Included :
1 x VC97 Digital Multimeter
1 x Leads
1 x Manual
1 x TP01 temperature probe
Details pictures :
Description :
VC97 Auto Range Digital Multimeter Capacitance Resistance Tester
Features :
Model : VC97
New type , streamline design.
Strong antimagnetic and performance.
Large LCD makes the reading clearly.
Full function protection.
Unit symbol display, very easy to reading.
Relative value, frequency/duty cycle measuring, data hold.
Specification :
Meter size : 185 x 90 x 35mm
Basic function
Range
Basic accuracy
DCV
400mV/4V/40V/400V/1000V
(0.5%+4)
ACV
4V/40V/400V/1000V
(0.8%+6)
DCA
400uA/4000uA/40mA/400mA/20A
(1.0%+5)
ACA
400uA/4000uA/40mA/400mA/20A
(1.5%+5)
Resistance
400/4k/40k/400k/4M/40M
(0.8%+1)
Capacitance
4nF/40nF/ 400nF/4F/40F/200F
(3.5%+8)
Frequency
100Hz/1kHz/10kHz/100kHz/1MHz/30MHz
(0.5%+4)
Centigrade temperature
-40C~1000℃ (can be converted toF)
(0.8%+4)
Special function
VC97
Diode
hFE
Continuity
Approx. less than 3010
Low indication
Approx less than 2.4V
Duty cycle measuring
Data hold
Auto off
Approx.15minutes
Function protect
Input impendence
10M
Sampling rate
3times/s
AC frequency response
40-400Hz
Operation way
Manual or auto range
. display
4000
LCD size
65x41mm
3V AAAx2
dissipation
Quiescent current approx. 2mA
Package Included :
1 x VC97 Digital Multimeter
1 x Leads
1 x Manual
1 x TP01 temperature probe
