Image Sensor 2MP CMOS Image Sensor
Signal System PAL/NTSC
Effective Pixels 1920(H) x 1080(V)
Min. Illumination 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR
Shutter speed 1 / 25(1 / 30) s to 1 / 50,000 s
Lens 3.6mm
Angle of view: 82.2°(3.6mm)
Lens Mount M12
Day & Night ICR
Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360°
Synchronization Internal Synchronization
Video Frame Rate 1080p@25fps / 1080p@30fps
Video Output 1 Analog HD output
S/N Ratio ?62dB
mage Sensor: 2MP CMOS Image
Sensor
Signal System: PAL/NTSC
Effective Pixels:
1920(H)*1080(V)
Min. Illumination: 0.01 Lux @
(F1.2,AGC ON),0 Lux with IR
Shutter Time: 1/25(1/30) s to
1/50,000 s
Lens: 2.8mm, 3.6mm, 6mm optional
Lens Mount: M12
Adjustment Range: Pan: 0 –
360Ã, Tilt: 0 – 180Ã, Rotation: 0 – 360Ã
Day& Night: IR cut filter
with auto switch
Video Frame Rate:
1080p@25fps/1080p@30fps
HD Video Output: 1 Analog HD
output
Synchronization: Internal
Synchronization
S/N Ratio: More than 62 dB
Megapixel high-performance CMOS
Analog HD output, up to 1080P resolution
True Day/Night
Smart IR
Up to 20m IR distance
IP66 weatherproof
Camera
Image Sensor: 2MP CMOS Image Sensor
Signal System: PAL/NTSC
Effective Pixels: 1920(H)*1080(V)
Min. Illumination: 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens: 2.8mm, 3.6mm, 6mm optional
Lens Mount: M12
Adjustment Range: Pan: 0 - 360Ã, Tilt: 0 - 180Ã, Rotation: 0 - 360Ã
Day& Night: IR cut filter with auto switch
Video Frame Rate: 1080p@25fps/1080p@30fps
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
S/N Ratio: More than 62 dB
General
Operating Conditions: -40 ÃC - 60 ÃC (-40 ÃF - 140 ÃF)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDCÃ15%
Power Consumption: Max. 4W
Weather Proof: IP66
IR Range: Up to 20m
Dimension: Ã70Ã149.5 mm (Ã2.76Ã Ã5.89Ã)
Weight: 400 g
