TECHNICAL SPECIFICATIONS
Basic InformationPart Number 50087399-001Model AP371Description AP371 (11be indoor, 2+2 dual bands, smart antenna, USB, BLE)First supported version V600R023C10Full Technical SpecificationsInstallation Type Wall, Ceiling, T-RailDiameter (mm) 180 mmHeight (mm) 35 mmWeight with packaging (kg(lb)) 0.69 kg (1.52 lb)Weight without packaging (kg(lb)) 0.47 kg (1.04 lb)Maximum number of physical ports on the entire device 2.5GE (RJ45) x 1, 100M/1000M/2500 Mbit/s auto-sensingMaximum power consumption (W) 13.60 WMaximum heat dissipation (BTU/hour) 44.1Power supply mode DC adapter, PoEInput voltage range (V) DC: 12 V & plusmn; 10%PoE: 802.3at/afRated input voltage (V) 12 V802.3at power supply description No function is limited.DC power supply description No function is limited.802.3af power supply description The USB function is not supported. Other functions are not restricted.Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax/be5 GHz:802.11a/n/ac/ac Wave 2/ax/beAntenna gain (dBi) 2.4 GHz:4 dBi/chain (peak gain)1 dBi (combined gain)5 GHz:5 dBi/chain (peak gain)3 dBi (combined gain)BLE: 4 dBi (peak gain)Maximum transmit power (dBm) 2.4 GHz:20 dBm/chain23 dBm (combined power)5 GHz:20 dBm/chain23 dBm (combined power)Radio number 2MIMO spatial streams Radio 0 (2.4 GHz): 2x2Radio 1 (5 GHz): 2x2Radio interface Built-in smart antennasOperating frequency band 2.4GHz,5GHzStorage NAND Flash 256MBLong-term operating temperature ( & deg;C( & deg;F)) & ndash;10 & deg;C to +50 & deg;C (14 & deg;F to 122 & deg;F) (From 1800 m to 5000 m (5905.51 ft. to 16404.20 ft.), the maximum temperature of the device decreases by 1 & deg;C (1.8 & deg;F) for every 300 m (984.25 ft.) increase in altitude.)Storage temperature ( & deg;C( & deg;F)) & ndash;40 & deg;C to +70 & deg;C ( & ndash;40 & deg;F to +158 & deg;F)Long-term operating relative humidity (RH) 5% RH to 95% RH (non-condensing)Long-term operating altitude (m(ft.)) & ndash;60 m to +5000 m ( & ndash;196.85 ft to +16404.20 ft)MTBF (year) 158.215MTTR (hour) 2USB The USB function is unavailable and will be supported through software upgrades.Console port BLE ConsoleAtmospheric pressure (kPa) 53kPa - 106kPa ETSI 300 019-2-3Service port surge protection (kV) PoE port:Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion BCommon mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion BGround Floating GroundBLE BLE5.43G/LTE filter (ACC) Supported
Ap 263(11ax Indoor,2+2 Dual Bands,smart Antenna,usb,ble)
AP263 is Huawei's Wi-Fi 6 (802.11ax) wall plate AP. This AP features high bandwidth, high concurrency, and compact size, facilitating flexible deployment and saving customer investment. It is applicable to indoor coverage in SME markets, such as SMB office, hospitals, and cafes.
Working simultaneously on the 2.4 GHz (2x2) + 5 GHz (2x2) frequency bands
Uplink: 1 x GE electrical port; downlink: 1 x GE electrical port
Various installation modes for easy deployment, including wall-mounting and plate-mounting
Built-in smart antennas to provide precise coverage for STAs, reduce interference, and improve signal quality
USB port for external IoT expansion (supporting protocols such as ZigBee, and RFID)
Bluetooth serial interface-based O & M through built-in Bluetooth by collaborating with CloudCampus APP
Working modes: Fit, Fat, and cloud management
The TP-LINK Wireless N Access Point TL-WA801ND is designed to establish or expand a scalable high-speed wireless N network or to connect multiple Ethernet enabled devices such as game consoles, digital media adapters, printers, or network attached storage devices to a wireless network. The APs support a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or with any other application that you may wish to use. Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through two antennas to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building.
Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not Supports multiple operation modes (Access Point, Multi-SSID, Client, Universal/ WDS Repeater, Bridge with AP) to enable various wireless applications to give users a more dynamic and comprehensive experience when using their AP. Multiple operating mode also helps you easily to build wireless network for hard-to-wire locations or eliminating wireless dead zone. The TL-WA801ND is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.
Wireless Gigabit Ceiling Mount Access Point - Omada Ac1350 - Eap225
Simultaneous 450Mbps on 2.4GHz and 867Mbps on 5GHz totals 1317Mbps Wi-Fi speedsFree EAP Controller Software lets administrators easily manage hundreds of EAPsCompatibility with 802.3af and Passive PoE support makes deployment effortless and flexibleCaptive portal provides a convenient method for guest authenticationBand Steering Automatically moves dual band devices onto the wider 5GHz band for faster connectionsMU-MIMO means access points simultaneously transfer data with multiple devices, speeding up connectionsBeamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experienceSupports management VLAN for an enhanced network managementSchedules can be set so access points automatically reboot and Wi-Fi turns on/off at the times you choose
EAP225 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter, making deployment effortless and flexible.
The Omada business-grade 11ac Wi-Fi solution is engineered to handle heavy multi-user usage in large areas without encountering the same stability issues found with standard routers and access points purposed for home use. It & rsquo;s the perfect fit for motels, salons, chain-stores, schools, and restaurants.
Outfitted with the latest 802.11ac Wave 2 M
Tp-link & rsquo;s 5ghz 300mbps 13dbi outdoor cpe, the cpe510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor wi-fi coverage applications. Professional performance, coupled with user-friendly design, makes cpe510 an ideal choice for both business and home users. With qualcomm atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and poe power supply, cpe510 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -30? (-22?) to +70 ? (158?). Built-in high gain dual-polarized antenna dedicated metal reflector ensures higher gain and lower noise interference.
OS3 5GHz Outdoor CPE is designed to PtP & P2MP solution for video surveillance transmission and wireless broadband access. Adopts of 11ac wireless technology, the maximum wireless rate can be up to 867Mbps. It features with 12dBi dual polarization directional antenna to provide an efficient way to pick up and maintain a stable long range connection.
5+km transmission range
OS3 adopts of internal power amplifier and 12dBi directional antenna to provide an efficient way to pick up and maintain a stable signal for a wireless network up to 5km.
Flexible power supply method enable it easy to deployment
OS3 supports 12V 1A Passive PoE and 12V 1A DC power supply option. It helps the engineer to deploy the device flexibly.
TD-MAX--Tenda TDMA proprietary protocol
TD-MAX is Tenda TDMA (Time Division Multiple Access) proprietary protocol to improve performance and capacity for wireless P2MP outdoor application scenarios. In outdoor environment, the CPE use highly directional antennas to connect to the Basestation from distances that can span several kilometers. the CPE can't sense each other, they become "hidden nodes & rdquo;and cannot coordinate access to the wireless channel. Thus the Basestation experiences frequent collisions from stations transmitting simultaneously. As the network scales, these collisions build up exponentially, increasing latency and lowering throughput. With TD-MAX, it coordinate all the data transmission and allocates time to active clients to provide greater noise immunity performance when compared to the conventional 802.11 CSMA/CA (Carrier Sense Multiple Access / Collision Avoidance) protocol.
Auto-bridge technology enable it to easy setup
OS3 supports auto-bridge technology, It enables the CPE or basestation in factory default settings to connect to each other automaticaly after the device is powered on. It is very useful for the person who is not familiar with network knowledge, especially for CCTV surveillance transmission application.
Easy to Setup and Manage
OS3 comes with a centralized management software that helps users easily to manage all the devices in the network from a single PC-CPE Assistant.
Professional Outdoor Design
Equipped with IP65 waterproof enclouse and high quality hardware design, OS3 can work in various weather conditions, such as sunshine, rainfall or extremely low/high temperature environment
Multiple Application Scenarios
PtP Connection For CCTV Transmission
One work as AP mode and another work as Station mode to create a long distance wrieless connecton for video surveillance.
PtP Connection For internet sharings
One work as AP mode and another work as Station mode to create a long distance wrieless connecton for internet sharing between buildings or neighbors.
Wireless Internet Access for Private ISP
Wirelessly connect to Private ISP tower signal to share Internet to local wireless and wired network.
The Comfast CF-E314N V2 is a wireless access point/router/Wifi repeater designed for extending network coverage and providing reliable connectivity
pecifications:
Wireless Standards: Supports 802.11n/g/b.
Frequency Band: Operates on the 2.4 GHz band.
Speed: Typically supports wireless speeds up to 300 Mbps.
Ports: Usually includes several Ethernet ports (often 1 WAN and 1 LAN) for wired connections.
Power Supply: Often powered by a standard power adapter or Power over Ethernet (PoE) for flexible installation.
Antenna: Features built-in dual 14 dBi antennas for improved signal strength and coverage.
Security: Supports WPA/WPA2 encryption for secure wireless connections.
Features:
Easy Setup: User-friendly interface for configuration and management.
Multiple Operation Modes: Can function as a router, access point, or repeater, depending on your networking needs.
Stable Performance: Designed to provide stable connectivity for various devices.
The Comfast CF-WR651AC is a wireless router designed for home and small office use, providing high-speed internet connectivity. Also support mesh technology with it peers.
Here are its key specifications and features:
Specifications:
Wireless Standards: Supports 802.11ac, 802.11n, 802.11g, and 802.11b.
Frequency Bands: Dual-band operation (2.4 GHz and 5 GHz).
Speed:
Up to 300 Mbps on the 2.4 GHz band.
Up to 867 Mbps on the 5 GHz band.
Ports: Typically includes multiple Ethernet ports (1 WAN and 1 LAN) for wired connections.
Antenna: Equipped with external antennas for improved range and signal strength.
Power Supply: Usually powered via an external adapter.
Security: Supports various security protocols like WPA/WPA2.
Features:
Easy Setup: User-friendly web interface for easy configuration.
Multiple Operating Modes: Can be used as a router, access point, or repeater.
Beamforming Technology: Enhances signal strength and coverage.
Guest Network: Option to set up a separate network for guests.
Ap661(11ax Indoor,2+2+4 Tri Bands,smart Antenna,usb,ble)
Huawei AP661 Indoor High-Density AP
The Huawei AP661 Indoor High-Density AP is a cutting-edge solution designed to meet all your wireless network needs. Crafted by Huawei, a leader in telecommunications, this access point ensures superior connectivity and performance. Ideal for areas with high user density, it offers a seamless and efficient network experience.
Key features and attributes:
High Performance: Equipped with the latest Wi-Fi 6 technology, the AP661 delivers exceptional speed and efficiency.
Multiple Device Support: Handles numerous devices simultaneously without compromising on performance.
Advanced Security: Provides robust protection against unauthorized access with enterprise-level security features.
Easy Installation: Compact design and versatile mounting options make it easy to deploy in various indoor settings.
Energy Efficient: Optimized power management ensures lower energy consumption without sacrificing performance.
Seamless Roaming: Offers uninterrupted connectivity for users moving between access points.
Customizable Coverage: Adjustable antenna settings let you tailor the coverage to your specific needs.
This high-density access point is perfect for offices, schools, and other environments where reliable internet access is crucial. The Huawei AP661 ensures your network remains stable and fast, even when under heavy load.
Invest in the Huawei AP661 Indoor High-Density AP for a robust and efficient wireless network solution. It combines high performance, advanced security, and energy efficiency to deliver among the best in connectivity. Upgrade your network today and experience the difference.
Access Point 362(11ax Indoor,2+2 Dual Bands,smart Antenna)
ItemSpecification
Installation Type
Wall
Ceiling
T-Rail
Dimensions without packaging (H x W x D) [mm(in.)]
Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.)
Dimensions with packaging (H x W x D) [mm(in.)]
200 mm x 231 mm x 52 mm (7.87 in. x 9.09 in. x 2.05 in.)
Weight without packaging [kg(lb)]
0.46 kg (1.01 lb)
Weight with packaging [kg(lb)]
0.80 kg (1.76 lb)
Storage
NAND Flash 256 MB
Console port
None
Maximum power consumption [W]
11.2 W
Power supply mode
DC adapter
PoE
Rated input voltage [V]
12 V
Input voltage range [V]
DC: 12 V & plusmn; 10%
PoE: 802.3af
Service port surge protection
PoE port:
Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C
Maximum number of physical ports on the entire device
GE (RJ45) x 1, 10M/100M/1000M auto-sensing
Long-term operating temperature [ & deg;C( & deg;F)]
& ndash;10 & deg;C to +50 & deg;C (14 & deg;F to 122 & deg;F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1 & deg;C [1.8 & deg;F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [ & deg;C( & deg;F)]
& ndash;40 & deg;C to +70 & deg;C ( & ndash;40 & deg;F to +158 & deg;F)
Long-term operating relative humidity [RH]
5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)]
& ndash;60 m to +5000 m ( & ndash;196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa]
53kPa - 106kPa ETSI 300 019-2-3
Ground
floating ground
BLE
Not supported
Radio number
2
Operating frequency band
2.4GHz
5GHz
MIMO spatial streams
Radio 0 (2.4 GHz): 2x2
Radio 1 (5 GHz): 2x2
Wi-Fi standard
2.4 GHz: 802.11b/g/n/ax
5 GHz: 802.11a/n/ac/ac Wave 2/ax
Radio interface
Built-in smart antennas
Antenna gain
2.4G:
4 dBi/chain (peak)
2 dBi (combined gain)
5G:
5 dBi/chain (peak value)
3 dBi (combined gain)
Maximum transmit power
2.4G:
20 dBm/chain
23 dBm (combined power)
5G:
20 dBm/chain
23 dBm (combined power)
Singal radio transmit power [dBm]
2.4G: -10 dBm to 20 dBm/chain
5G: -10 dBm to 20 dBm/chain
MTBF [year]
205.07 year
MTTR [hour]
0.5 hour
Frequency stability [ppm]
+/-20
802.3bt power supply description
No function is limited.
802.3at power supply description
No function is limited.
802.3af power supply description
No function is limited.
DC power supply description
No function is limited.
Nova Mx3 Ax1500 Whole Home Mesh Wi-fi 6 System - 3 Pack
Tenda Nova MX3 3-pack AX1500 Whole Home Mesh Wi-Fi 6 System
MX3 is a Mesh Wi-Fi system designed to provide whole-home Wi-Fi 6 for medium to large houses. Supporting easymesh technology, the MX3 is equipped with high-performance enhancement modules for powerful penetration and broader coverage. It can easily cover up to 300m & sup2; 3500ft & sup2; with 3 nodes. MX3 supports OFDMA and MU-MIMO technology so that multiple devices can be connected simultaneously without dragging down performance. It's easy to set up in 3 steps, you can enjoy a fast wireless network at any time.
Features
Intelligent Troubleshooting
With built-in intelligent network failure diagnosis function, it can easily solve common network failures.
One Wi-Fi Name,Smooth Seamless Roaming
MX3 units work together under one unified network supported by 802.11k/v protocol and AP steering technology, creating seamless roaming experiences. Your devices will automatically connect to the best node as you move around in your house.
Multiple Connections Can Also be Stress-free
Supporting OFDMA and MU-MIMO technology, MX3 is tested to connect over 80 devices simultaneously without dragging down performance.
Perfect match for starlink and Fiber Networks
Better and Cheaper than TP-Link Deco M5
