Key Features
Order Number: 3v110-06/Ac220v
Brand: SNS/Shenchi
Item No.: 3v110-06/Ac220v
Model: 3v110-06/Ac220v
Material: Aluminum Alloy
Type (Channel Location): Three Way Type
Connection Form: Thread
Applicable Medium: Air
Flow Direction: Reversing
Purpose: Reversing
Nominal Diameter: See Details mm
Operating Temperature:-20~70 ℃
Number of Locations: See Details
Operating Pressure: 1mpa
Effective Cross-Sectional Area: See Details Mm²
Manner of Execution: Pilot Type
Maximum Action Frequency: See Details
3C Valve Category: Industrial
Specifications: 3v110-06/Ac220v, 3v110-06/Dc24v with Cable, 3v210-06/Ac220v, 3v210-06/Dc12v, 3v210-06/Dc24v, 3v210-08/Ac220v, 3v210-08/Dc12v, 3v210-08/Dc24v, 3v310-08/Ac220v, 3v310-08/Dc12v, 3v310-08/Dc24v, 3v310-10/Ac220v, 3v310-10/Dc12v, 3v310-10/Dc24v, 3v410-15/Ac220v, 3v410-15/Dc12v, 3v410-15/Dc24v, 3v110-06/Ac220v with Light, 3v110-06/Dc24v with Light
Whether Cross-Border Export Is Exclusively Available: No
