This audio mixer is professional and compatible with any of your devices. It helps with reverb qualities, has an ARM chip. Audio mixer with delay, pitch changing. Works with low noise. . LED turns on when the signal after EQ reaches 3dB below distortion. Switchable EFX/G1, G2 signals will receive before or after the channel volume control Level indicates the MAIN STEREO LEVEL knob, the green light will be on. When the signal after MAIN Level reaches 0dB, the red light will be clipped. When the signal reaches 0dB below the distortion, the LED will turn on and light up. Input and output level : MIC (-60dB) LINE ONPUT (-40dB)
SPECIFICATIONS
1.Frequency response:
Input to stereo out 0.5 dB / - 1.0 dB (20 Hz ¬ 20 kHz).
Reference output level rate: 1kHz.
Gain knob: Medium
2.THD + N:
0.02% @ + 10dbu (20 Hz to 20kHz).
Gain knob: Medium
3.Input channel: MIC * 5, 2RCA, PC, 2LINE, USB, Wireless, 3.5MINI
4.Output channel:
STEREO OUT:2
PHONES:1
3.5MINI MAINPH OUT:1
3.5MINI LOOPBACK output
5. Bus: STEREO: 1
6. Input channel: HPE (mono): 80Hz, 12dB / octave (CH3, 4)
7. EQ HIGH Gain: + 15dB / - 15dB, Frequency: 10kHz slope
EQ LOW Gain: + 15dB / - 15dB, Frequency: 100Hz slope
PEAK LED: When EQ signal reaches 3dB below distortion, LED switch ON
8.MAIN STETREO LEVEL When the signal level reaches 0dB, the green light is ON, when it reaches 3dB below the distortion, the red light is ON.
9.Input and output level: Mic (- 60dB) LINE (- 40dB)
