7 Channel Audio Mixer / Mixing Console With Usb Interface
F7 channels Analog Audio Mixer is suitable for DJs,small events or gathering and even big live performance shows. Coupled with the best designed materials, this mixer gives a sound quality that almost match a professional set-up.Due to its phantom it makes it usable with condenser mics therefore making it also recommendable for big and small scale studios. Also have EQs on each channels
This is a professional 4/7-channels mixing console with equalizer and Aux paths plus effects processor,it's a 7-channel mixing console with two stereo channels and a separate stereo channel,separate input jack control for mix and line input noal channels,xlr mic connector on all mono channels,low noise discrete mic preamplifier on all microphone input,dedicated insert on all mono channels,Balanced 1/4" stereo jacks and balance controls on all stereo channels,separate stereo tape channel with 1/4" and RCA jacks,stereo output for recording applications,English musical active 3 band equalizer on all four channels,Aux and effects paths as well as separate gain controls on channels,high grade sealed faders and pontentiometers made by Taiwan,insert option for external effects device,Aux send and eff send controls in the main section for optimal level adjustment,headphones output with dedicated volume control,built in +48V phantom power for condenser mics,extremely rugged construction ensures long life even under the most demanding conditions.
Specifications
MIC INPUT:
Frequency response:20Hz to 25KHz +1dB
Gain range:+6dB to +60dB
SNR:120dB E.I.N
LINE INPUT:
Frequency response:20Hz to 25KHz +1dB
Gain range:-14 dB to 40dB
SNR:95dB
STEREO CHANNELS:
Frequency response:20Hz to 25KHz +1dB
Gain range:line:-20dB to +10dB
SNR:line:96dB
EQUALIZATION
LOW:80Hz +/-15 dB
MID:2500 Hz +/- 15dB
HI 12khz +/- 15dB
This mixing console can used anywhere like churches, mosques,clubs and many more it has usb, and Bluetooth.it also has equalizer
For musical and non-musical applications alike, effects processing adds polish and professionalism to the mix. The MG X / XU models features Yamaha's acclaimed SPX digital multi-effect processor, offering a comprehensive suite of 24 editable digital effects perfect for enhancing your mix, whether adding depth to a speaking engagement or breathing new color and atmosphere into a live band performance. In particular, the high-quality reverb and delay expand the spatial quality of the sound with remarkable realism and naturalness.
Delivering fat, natural sounding bass and smooth, soaring highs, with very low distortion, D-PRE preamps possess an impressively wide frequency range that allow them to handle signal from any audio source without overly amplifying any specific elements of the sound. Having such a pure sonic platform to build on will ultimately save you time and effort by eliminating the need for excessive EQing or additional effects processing in order to "fix" your mix.
Built to last, MG Series mixers feature a rugged, impact-resistant, powder-coated metal chassis, offering an unrivaled level of durability. With a sleek design contoured for optimal convection cooling, the internal layout separates the power supply from the analog circuitry for superior noise reduction, and further extends the life of the components inside. To further ensure reliable performance, knob control placement above the surface of the chassis diverts any impact or pressure on the knobs to the chassis itself and not the circuit board or components underneath.
MG Series mixing consoles feature flexible digital connectivity for quick and easy highresolution playback of digital content. Simply connect to your PC via USB, or to your iPhone / iPad (2 or later) using Apple's Camera Connection Kit / Lightning to USB Camera Adapter. The USB protocol uses asynchronous data transfer. Audio data is transferred based on highly precise audio clock signal from the MG, for high quality recording and playback.
Compression plays an essential role in just about any recording or sound reinforcement environment by altering the level of dynamics of an audio signal when you need livelier guitars, punchier bass lines, a tighter snare, or a cleaner vocal sound. However, it can take countless hours to master the complexities of even the most basic outboard compression units and use them effectively. Originally a Yamaha innovation, 1-knob compressors are now an industry standard that gives you instant access to optimized compression settings via a single rotary control.
16-Input Stereo USB Mixer Features16-Channel Mixing ConsoleMax. 10 Mic / 16 Line Inputs (8 mono + 4 stereo)4 GROUP Buses + 1 Stereo Bus4 AUX (incl. FX)D-PRE mic preamps with an inverted Darlington circuit1-Knob compressorsHigh-grade effects: SPX with 24 programs24-bit/192kHz 2in/2out USB Audio functionsWorks with the iPad (2 or later) through the Apple iPad Camera Connection Kit / Lightning to USB Camera AdapterIncludes Cubase Al DAW software download versionPAD switch on mono inputs+48V phantom powerXLR balanced outputsInternal universal power supply for world-wide useRack Mount Kit IncludedMetal chassis
This is MG16XU mixing console for professional audio application.whether out on the road touring.in small meeting room,a bar or earning its keep in rental stock,the mixer provides the perfect solution to provide simple and convenient connection and quickly form a sound amplifying system.Engineered to the same exacting standard as our top range consoles it ensures the highest reliability and finest sonic performance.
COMPRESSOR:
Built-in channels dynamics is normally a feature reserved for professional digital consoles.These unique one knob compressors are surprisingly simple to use.just set the comp control to the amount of compression you need.
6,8,12,16 channel frame
LR main mix
2 Aux send
Recording
Responsive 3 band EQ
Individual phantom power
channel and master meters
60mm dust protected fader
2-Track monitoring and reply to LR Headphones and local monitor output,dedicated stereo,peak retaining monitor meters,Electronically balanced XLR output with +26dbu drive capability
utra low noise mix head amp design
Bluetooth & MP3 player/recorder with concise human-machine interactive interface.
digital effect processor
metal jacks gold plated xlrs sealed pots and switches
External power adapter power supply.
16 input channels
6 busses (stereo & 4 groups
Rack mountable
3 band mid sweep (ch 1-8)/3 band (ch 9/10-15/16)EQ
The top of the MG live-sound mixer series, with outstanding sound quality and an extensive range of powerful features.
MG24/14FX
24 Input channels (16 Mic inputs, 4 Stereo line inputs, 16 Insert I/O)Dual SPX Digital EffectsVersatile EQ for Effective Sound ShapingSix Aux Sends & Two Stereo Aux Returns14 Buses In All For Flexible Signal Routing
Serious Consoles for Live Sound or Installations
The MG24/14FX and MG32/14FX are full-featured sound reinforcement consoles with capacity and capabilities that can handle demanding live sound applications. Choose the 24-input MG24/14FX or 32-input MG32/14FX according to the number of sources you need to handle. All other features are the same, including two renowned Yamaha SPX effect processors built in. Extensive routing capability is also provided for monitoring and external signal processing, as required by your application.High Input Capacity for Live Sound
The MG24/14FX has 16 mono inputs and 4 stereo inputs, while the MG32/14FX has 24 mono inputs and 4 stereo inputs. Input gain controls and pad switches allow optimum matching with the widest possible range of sources: microphone levels can be adjusted from -60 dB to +10 dB, while line levels can be adjusted from -34 dB to +10 dB. Channel peak indicators are provided to facilitate optimum level matching.Versatile Inputs
The monaural inputs provide both balanced XLR and phone jacks - that's channels 1 through 16 on the MG24/14FX, and channels 1 through 24 on the MG32/14FX. Two of the stereo inputs offer phone jacks as well as RCA pin jacks. Independent 2-track RCA pin jack inputs are also provided for input from CD players or other stereo line-level sources.Top-quality Microphone Preamps
Microphone preamplifiers play a vital role in determining the final sound of your mixes. The MG-series mixers feature low-noise, high-performance microphone preamplifiers that will bring out the best in dynamic and condenser type microphones. Microphone preamplifiers are provided on channels 1 through 16 of the MG24/14FX, and on channels 1 through 24 of the MG32/14FX.Switchable Phantom Power
The MG mixer microphone preamplifiers provide 48-volt phantom power for studio-quality condenser microphones. Phantom power can be switched on or off for in 8-channel groups.Insert I/O
Mono input channels feature insert patch points that can be used to insert external signal-processing devices into the channel's signal path. Insert I/O points are also provided on the stereo bus (L and R) and on the four group buses.Mid-sweep 3-band Mono Channel EQ, 4-band Stereo Channel EQ
The mono channels on both the MG24/14FX and MG32/14FX offer advanced EQ facilities: 3-band EQ with a 10 kHz shelving HIGH control, a 250 Hz ~ 5 kHz sweepable MID control, and a 100 Hz shelving LOW control. The microphone inputs also have switchable 80 Hz high-pass filters for low-frequency noise reduction. The stereo channels feature 4-band EQ with 10 kHz HIGH, 3 kHz HI MID, 800 Hz LO MID, and 100 HZ LOW controls.Multi-bus Configuration with a Total of 14 Buses
In addition to the main stereo bus that feeds the console's main outputs, the MG24/14FX and MG32/14FX feature four group buses for convenient sub-mix grouping, six auxiliary buses for monitoring and external effect send, and send buses for the two internal effect processors. That's a total of 14 buses in all for exceptionally flexible signal routing. The channel send knobs and bus assign switches make it easy to send the signal from each channel to the stereo, group, internal effect, and auxiliary buses as required.Ample Sends and Returns
All input channels have a total of six auxiliary sends: AUX send 1 through 4 can be switched for pre- or post-fader operation, while AUX sends 5 and 6 are post-fader. Two EFFECT sends are provided in addition to the six AUX sends. That's more than sufficient send capability to handle monitoring and effects for all but the most complex applications. Two stereo AUX returns are provided in addition to the internal effect returns, providing an extra margin of return versatility for wet monitoring, for example.Comprehensive Output Connectors
The mixer's main stereo program signal is simultaneously delivered to the main stereo outputs (XLR jacks), the sub-stereo outputs (phone jacks), the REC OUT connectors (RCA pin jacks), the mono out (XLR jack), and the headphones output (stereo phone jack). Independent phone-jack outputs are also provided for group buses 1 through 4. So even if you need to feed a front-of-house system, monitors, a subwoofer, a master recorder, and other output lines simultaneously, the MG24/14FX or MG32/14FX will handle it.Reliable XLR Output Connectors
The main stereo outputs and mono output feature rugged, reliable XLR type connectors. Not only do these connectors lock to minimize the chance of accidental disconnection, but they provide superior electrical contact for long-term dependability as well.Variable LPF on the Mono Output
A low-pass filter with a roll-off frequency that can be varied from 80 to 120Hz is provided on the mono output for convenient connection and optimum matching with a subwoofer.12-segment Level Meters
Four high-visibility 12-segment meters are switchable to allow precise visual monitoring of levels on the main stereo bus, the four group buses, the stereo 2-track input, the PFL (Pre-Fader Listen) bus, or the AFL (After-Fader Listen) bus.High-performance Digital Effect Processors Built In
Both the MG24/14FX and MG32/14FX contain a powerful pair of Yamaha digital signal processors that provide a useful selection of 16 advanced digital effects. Effect programs include reverb, delay, pitch change chorus, phaser, voice doubler, and distortion. The effects include editable parameters so they can be customized as required, and processor "B" even has a TAP switch for real-time tap-tempo entry. With these top-performance effect processors built in, you wont have to transport and set up racks of external effects to create your sound.Illuminated Switches for High Visibility
The channel ON switches, PFL (Pre-Fader Listen) switches and phantom power switches are original Yamaha illuminated types, so it's easy to visually check vital console settings.Talkback for Convenient Communication
A talkback microphone input is provided for easy, efficient communication between the sound engineer and musicians and staff in live-sound applications, during setup, rehearsal, and the actual performance.Intuitive Controls and High Reliability
The design of the faders, rotary controls and switches used on the MG mixers, as well as the way they are laid out, allow easy operation and visual confirmation of settings.
Input characteristicsInput termial PAD GainTrim Actual LoadImpedance For Use WithNominal Input Level Connector In MixerNominal Max. before ClipCH INPUT [A, B] *1 0 -60 3 ohms 50-600ohm Mics & 600 ohm Lines -60dBu -40dBu A: XLR-3-31typeB: TRS phone jack26 -34dBu -14dBu0 -16 -16dBu +4dBu26 +10dBu +30dBuST CH INPUT *2 -34 10 ohms 600ohm Lines -34dBu -14dBu TRS phone jackRCA Pin jack10 +10dBu +30dBuCH INSERT IN *1 10kohms 600ohm Lines 0dBu +20dBu TRS phone jackGROUP INSERT IN (1-4) 10kohms 600ohm Lines 0dBu +20dBuSUB IN (1, 2) [L, R] 10kohms 600ohm Lines +4dBu +24dBu TRS phone jackTB IN 10kohms 50-600ohm Mics -50dBu -30dBu XLR-3-31 type2TR IN [L, R] 10kohms 600ohm Lines -10dBV +10dBV RCA Pin jack
*0dBu=0.775 Vrms.*1. MG24/14FX: 1-16, MG32/14FX: 1-24*2. MG24/14FX: 17-20,MG32/14FX: 25-28Output characteristicsConnection Actual SourceImpedance For Use WithNominal Output Level Connector In MixerNominal Max. before ClipST OUT [L, R]MONO OUT 75ohms 600ohms Lines +4dBu +24dBu XLR-3-32 typeGROUP OUT (1-4)AUX OUT (1-6) 150ohms 600ohms Lines +4dBu +20dBu TRS phone jackST SUB OUT [L, R])EFFECT OUT (1, 2) 150ohms 10kohms Lines +4dBu +20dBu TRS phone jackCH INSERT OUT *1GROUP INSERT OUT (1-4)ST INSERT OUT [L, R] 150ohms 10kohms Lines 0dBu +20dBu TRS phone jackREC OUT [L, R] 600ohms 10kohms Lines -10dBV +10dBV RCA Pin jackPHONES OUT 100ohms 40ohms Phones 3mW 75mW ST phone jack
*0dBu=0.775 Vrms.*1. MG24/14FX: 1-16, MG32/14FX: 1-24*2. MG24/14FX: 17-20,MG32/14FX: 25-28
7 Channel Audio Mixer With Bluetooth & Usb + Phantom Light
Brand
YAMAHA
This 7 channels mixer Analog Audio Mixer (F7) is suitable for DJs, small events or gathering and even big live performance shows. Coupled with the best designed materials, this mixer gives a quality sound that almost match a professional setup. Due to its phantom it makes it suitable with condenser mics therefore making it also recommendable for big and small scale studios. Also have equalisers on each channels
USB Function
7 Channel Mixer
2 XLR mono input Mic and 2 groups of stereo input channels
3-band EQ on all channel
Built-in digital delay ECHO effect Processor
Individual Gain,Bass,Mid High,Aux,controls
Stereo RCA Outputs for Recording
One AUX output
Main Slide control(L+R),Phone
Individual Echo,peak LED on each inputs
48 volt Phantom power
Delay,repeat,effect send & AUX Controls
Built-in balanced & unbalanced recording and playback connector
Package include:
1x Mixer
1x AV Cable
1x Adaptor
It has Bluetooth, USB mouth, Phantom power for microphone, 7 mic lines, smooth feel touch.
Mg166cx Usb 16-channel Usb Mixer With Compression And Effects
Whether you have a mixing application that involves only a few channels, or up to 32 inputs with substantial signal routing versatility, Yamaha's MG series offers a mixing console that will give you the capacity, control, and performance you deserve. All models are remarkably compact and lightweight for superior handling and portability, but absolutely no compromises have been made in terms of features, performance, or durability. The MG mixers offer an extraordinary blend of technology: some inherited from professional Yamaha mixing consoles you're likely to see in distinguished halls throughout the world, and some developed specifically to deliver optimum performance in the MG-console format. In either case these performance-packed Yamaha mixers are founded on a world-spanning network of human and technological resources that crystallize to deliver features that really matter, and sound that is undeniably superior.
FEATURES
Built-in SPX Digital Effects
Easy operation
Lightweight, portable design
Versatile connectivity and pro-class connectors
Built-in channel compressors
High-performance microphone preamplifiers with switchable phantom power
3-band Channel EQ and high-pass filters
Aux/Effect sends
Smooth 60mm faders and illuminated channel ON switch
12 channels mixing console with XLR, LINE inputs and 48V phantom power. - Each channel has GAIN, 3-band EQ, AUX, EFFECT, PAN control knobs and volume control faders. - The PEL switch allow you to monitor the channel that the PEL is turned "ON" only. - AUX send & return jacks for connecting all kinds of effects from outside. - With XLR(L/ R) & 1/4"(L/ R) stereo output jacks and REC(L/ R) & headset interfaces. - With USB input interface and LCD display as well as control buttons. - With power and output level indicator lights for easy monitoring and operation. - EFFECT level and output MAIN Faders, REPEAT, EFF SEND, DELAY, SEND, RETURN knobs on the master section.
3-band EQ and high-pass filters give you maximum control and eliminate unwanted noise, resulting in a cleaner mix
1-Knob compressors allow easy control - resulting in livelier guitars, punchier bass lines, a tighter snare and a cleaner vocal sound.
The mixers feature a rugged, impact-resistant, powder-coated metal chassis.Crosstalk:-78 dB
For more than a century, Yamaha has been building a legacy of superior craftsmanship and innovation exemplified in all of our products, from an unrivaled catalog of world-class musical instruments to touring-grade professional audio. Now in its third incarnation, the MG Series embodies this pursuit of design excellence, and incorporates some of the same technologies developed for use in high-end professional consoles, including studio-quality preamps, powerful digital processing, and a rugged, reliable construction.
With an intuitive, easy-to-use interface, the MG Series boasts an extensive lineup of compact mixing consoles with models ranging from six to twenty channels, suitable for a diverse range of users and applications. For installed, recording, or live music settings, the solid construction and flexible design of these consoles lets you shape your sound with confidence, continually delivering a level of sound quality and reliability unrivaled in its class.
4 channels/inputs.
USB MP player and to play music from directly with needing any audio player.
Uses power adaptor for powering mixer(included).
Ideal for DJs and any event.
Also ideal for big and small scale studio recording.
It has phantom power thereby making evem more recommendation for studio work and live musical performance.
This Portable Mixer gives you total control over each microphone channels.
Phantom powered;so it is also very suitable studio use for day-to-day recording.
