Hana motherboard
- Form factor: Micro ATX: 24.0 x 24.0 cm (9.45 x 9.45 in)
- Chipset: B550
- Memory sockets: 4 x DDR4 (288-pin)
- Processor socket: AM4
- Expansion Slots
- One PCI Express 4.0 x16 lanes
- One PCI Express 3.0 x1 lanes
- One M.2 socket 1, key A
- Two M.2 sockets 3, key M (one for SSD card PCIe x4 Gen 3)
- For more details, see Hana motherboard specifications.
- AMD Ryzen 7 5800X
- 3.8 GHz Base clock, up to 4.7 GHz Maximum Boost clock
- 4 MB L2 Cache and 32 MB L3 Cache
- 8 Cores and 16 Threads
- TDP: 105 W
Processor upgrade information
TDP: Up to 105 W
Socket type: AM4
Hana motherboard supports the following processor upgrades:
HyperX XMP RGB 16 GB
Amount: 16 GB
- Speed: PC4-25600 MB/
- Type: DDR4-3200
- Memory upgrade information
- Dual channel (2 DIMMs per channel) memory architecture
- Four DDR4 UDIMM (288-pin) sockets
- Supports up to PC4-25600 (DDR4-3200)
- Supports 8 GB and 16 GB DDR4 UDIMMs
- Supports up to 4 GB on 32-bit systems
- NVIDIA GeForce RTX 3060 Ti with LHR (8 GB) Graphics Card
- Form Factor: Full height PCB, 6-layer, with ATX dual slot bracket
- Dimensions: 20.3 cm x 11.2 cm (8.0 x 4.4 in)
- Rear I/O connectors: (3) DisplayPort 1.3/1.4 ready and (1) HDMI 2.1
- Maximum resolutions:
- HDMI 2.1 resolution: 4096 x 2160 x 24 bpp at 60 Hz
- DisplayPort resolution (1.3/1.4 ready): 7680 x 4320 at 60 Hz YUV 420 8-bit
NOTE: Not all ports support the highest resolutions.
-
Memory size: 8 GB (256-bit)
-
Memory type: 256M x 32 GDDR6 with 8 pcs
-
Engine clock: 1410 MHz (Base) and 1665 MHz (Boost)
-
Memory clock: 7000 MHz
-
Total power consumption: 200 W
-
Cooling: Active fan-sink with 4-pin fan control
-
DirectX: DX 12
-
PCIe: PCIe Gen 4.0 x16
-
Supports up to four displays simultaneously
