Honeywell’s MK7120 Orbit® provides aggressive omnidirectional scanning in an award-winning design for retailers seeking an affordable, aesthetically pleasing scanning solution. Orbit, the all-time, best-selling hands-free omnidirectional scanner, presents an innovative, elegant and affordable solution to convenience retail applications where counter space is at a premium. Compact, lightweight and rugged, Orbit maximizes customer satisfaction and employee effi ciency with a patented 20-line scan pattern, an easyto-fi nd sweet spot and a scan speed of 1,120 scans per second. The scanner’s expanded ability to update its fi rmware via Honeywell’s patented MetroSet®2 confi guration software (provided free) safeguards long-term infrastructure commitments in the event of a change in the POS system or software. Recipient of multiple design honors, Orbit’s award-winning shape enables hand-held scanning of large, bulky items. For added fl exibility, the scanning head can be tilted within a 30° range to accommodate objects of various sizes and shapes. Standard features include user-replaceable cables, Honeywell’s patented MetroSelect and MetroSet®2 for easy confi guration, data editing and OPOS/JPOS compatibility for easy installation.
Features
20 Scan Line Omnidirectional Pattern: Provides aggressive scanning as an additional benefi t to hand presentation applications
Sweet Spot Scanning: Engineered “sweet spot” to optimize scan performance and first pass read rate
Adjustable Scan Head: Ability to tilt scanner 30° for targeted scanning or larger products
Flash ROM: Protects POS investment with free firmware updates via MetroSet®2 software and standard PC
Automatic Scanning Operation: Simply present a bar code and the unit scans in a single pass.
Technical Information
Barcode Dimension: 1D
Scan Pattern: Single Line/ Omni-directional
Connectivity Technology: Cable
Light Source: Laser
Barcode Symbology Supported: Reads standard 1D and GS1 DataBar symbologies
Maximum Scan Resolution: 5 mil
Depth of Field:
o 0 mil - 2"@5.20 mil
o 0 mil - 5.90"@7.50 mil
o 0 mil - 6.90"@10 mil
o 0 mil - 8.50"@13 mil
o 0 mil - 9.80"@26 mil
General Information
Product Type: Desktop Barcode Scanner
Brand Name: Honeywell
Manufacturer:
Product Model: MK7120-38-3
Product Name: Orbit 7120 Omnidirectional Laser Scanner
Product Line: Orbit
Physical Characteristics
Height: 5.9"
Width: 4"
Color: Black
Length: 4.1"
Weight (Approximate): 14.10 oz
Interfaces/Ports
Host Interface: USB
Other
Certifications & Standards:
o Laser Class 1:
o EN: 60825-1:1994+A11:1996+A2:2001
o EMC:
o Class B: FCC Part 15
o ICES-003
o EN 55022 Class B
Additional Information: Supported Interface: USB
