Media Audio Playback |
CD playback disc | No |
Loader type | Front |
CD ripping speed | No |
Programmable track | Yes |
USB version | V1.1 |
USB playback (Files and folders number) | FOLD (99) / FILE (999) / FAT/VFAT32 USB |
USB ripping | No |
USB Mass Storage Device (ID3 Tag display) | No |
USB charging (A) | 0.5A |
Drivers |
Drivers: Magnectical shield | No |
Drivers: Speaker net | Yes |
Drivers: Cable terminal type / Insert Nut | Solder |
Cable length / Cable color | External expose 1m / black white |
L/R tweeter: Box type | Bass Port |
L/R Tweeter Bar Freq Response | 2KHz-20kHz |
L/R Tweeter Speaker Unit Tweeter | 1.5″ x 2 |
Woofer: Box type | Bass Port |
Woofer: Box volume | 3.95L |
Woofer: Bar Freq Response | 60Hz-10kHz |
Woofer: Speaker unit | 4″ x 2 |
Terminals |
Input | Aux-in (3.5mm jack) |
Output | No |
Functions |
Key | Tact Key |
Bluetooth | Bluetooth Function Version 4.2 / F-6699 |
Software Upgrade | USB upgrade |
Power Supply |
Voltage | AC ~ 100-240V |
AC: Internal/external power supply | Internal |
Power Output | 25W x 2 10% |
Packaging |
Printing Materials | POP sticker, QSG, User Manual, Warranty Card |
Audio Accessories |
| |
Antenna: FM /AM | FM |
Remote control | Same HA550 |
Battery for remote control | Yes |
Microphone | No |
Certification |
Logo | None |
Certifications | Bluetooth, CE, ERP II |
User Interface |
LED indicator | Red (1pcs) |
Display: Screen Type (LED/VFD/LCD) | LED |
Display: 7-Segment display /matrix display/Dot matrix screen/QTY | 8 Characters |
Display Colour | White |
Display: Brightness control / Dim | No |
Key | Tact Key |
Connectivity |
Speaker Out: Power | 25W x 2 10% |
Speaker Out: Amp type | 2 |
Input | Aux-in (3.5mm jack) |
Output | No |
WiFi Jack | RJ45 ethernet – No |
Bluetooth | Bluetooth Function Version 4.2 / F-6699 |
Bluetooth: Streaming Format | SBC |
Bluetooth: Playback & volume control (AVRCP) | 1 |
Bluetooth: Two-way volume sync | No |
Bluetooth: Handsfree calling (HFP) | No |
Bluetooth: Multipair support | 1 |
Bluetooth: Multipoint support | 6 |
Bluetooth: True Wireless Stereo (TWS) | No |
Bluetooth: Multi-speaker system | No |
Bluetooth: Enhanced operation range beyond | No |
Bluetooth Battery level | No |
Bluetooth connect at Standby mode | No |
NFC: Tap to wakeup | No |
NFC: Tap to pair | No |
NFC: Type A | No |
NFC: Type F | No |
NFC: Tap to break-in | No |
Voice Control | No |
DLNA/UPnP | No |
Network | No |
APP | No |
Bluetooth: Solution | BK3260N |
Specifications |
Solution (Main ChipSet) | AliM5677 |
Gross Dimension (W x H x D) | Main: 180 x 122 x 222.5mm, Speaker: 133 x 200 x 220mm |
More |
Bluetooth: Music streaming (A2DP) version | 1.2 |
AirPlay: AirPlay audio streaming | No |
AirPlay: Music metadata display | No |
Audio playback format | MP3, WMA |
