Image Sensor:
1/3" CMOS Sensor
Max Resolution:
2560x1792
Effective Pixels:
5.0MP
Compression Standard:
H.264/H.265
Framerate:
25fps
Bitrate:
Main Stream: 317Kbps ~ 8Mbps
Sub Stream: 68Kbps ~ 2728Kbps
SNR (Signal-to-Noise Ratio):
52dB
Min. Illumination:
0Lux (light ON)
Lens:
Interface Type: M12
Lens: 2.8mm
FOV (Field of View): H 96°, V 53°, D 110°
Function:
Audio Codec: G.711U/G.711A (default)
Exposure Control: Auto
White Balance: Auto
Gain Control: Auto
Digital 3D Noise Reduction: Support
OSD (On-Screen Display) Information Setting: Large font OSD, OSD flashing on alarm, OSD position settings
SNTP (Simple Network Time Protocol): Support
Schedule Reboot: Support
Smart Defog: Support
Motion Detection: Support Humanoid Detection
Image Setting: Support Saturation, Brightness, Contrast, Sharpness adjustment
Image Style: Standard, Soft, Transparent
Day and Night Function: Auto, Always Black & White, Always Color, Scheduled Color
Privacy Mask: Support up to 8 areas
Night Vision Optimization: Support
DWDR (Digital Wide Dynamic Range): Support
Screen Settings: Screen mirroring, Screen flipping
IP Adaptation: Support automatic adaptation of IP address (Optional)
Intelligent Analysis: Support Region Intrusion Detection, Line Crossing Detection, Video Blocking Detection, People Counting
Alarm Method: Email Alarm, Client Alarm
Remote Operation: System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis
Audio Function: Built-in Mic and Speaker
SD Card: Support up to 512GB
VQC (Video Quality Control) Technology: Support
Network:
Ethernet: 10/100Mbps Ethernet
Stream: 2x Streams
Network Protocols: HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
ONVIF: Standard ONVIF
Network Transmission: CloudSEE 2.0
Browser: IE8+, Chrome18+, Firefox5.0+, Safari5.02+
User: Up to 13 Users
App: Support iOS/Android
General:
Lights: 2 White LEDs + 2 IR LEDs
IR Distance: Up to 30 Meters
Waterproof Level: IP67
Power Supply: DC12V or PoE (IEEE802.3af)
Power Consumption: <4W (During Day); <6W (At Night)
Working Temperature: -25°C ~ 55°C
Working Humidity: 5% ~ 95% Rh
Color/Material: White/Plastic+Metal
Dimensions (WxHxD): 106x94x106mm
Weight: 320g
Installation Method: Wall or ceiling mount
