MEMORY
Memory
1 GB
BOX CONTENTS
What's in the box
HP DesignJet T630 36-in Printer, printer stand, automatic sheet feeder, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord
CONNECTIVITY AND COMMUNICATIONS
Connectivity, standard
Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct
Print multi-size files in one click
Yes
Remote print enabled
Yes
WEIGHTS
Weight
34.7 kg
Package weight
55.3 kg
DIMENSIONS
Minimum dimensions (W x D x H)
1317 x 605 x 932 mm
Package dimensions (W x D x H)
1470 x 575 x 590 mm
BATTERY AND POWER
Power
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max. Not dual voltage, power supply varies by part number with # Option code identifier.
Power consumption
<35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (standby)
SOFTWARE AND APPLICATIONS
Software included
HP Click, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant
WARRANTY
Manufacturer Warranty
One-year limited hardware warranty
CARTRIDGES AND PRINTHEADS
Number of print cartridges
4 (C, M, Y, K)
Ink types
Dye-based (C, M, Y)
pigment-based (K)
Color(s) of printing supplies
Cyan, magenta, yellow, black
Ink drop
5.5 pl (C, M, Y)
12 pl (K)
Print cartridge volume delivered
80 ml (K)
38 ml (K)
29 ml (C, M, Y)
Print head nozzles
1376
Print heads
1 (cyan, magenta, yellow, black)
High capacity of page yield (colour)
20 ml of ink yields 101 A1 pages, taking into account maintenance routines[2]
PRINTER SPECIFICATIONS
Functions
Print
Internal Storage
None
Print technology
HP Thermal Inkjet
Print languages
HP-GL/2, HP-RTL, CALS G4, JPEG, URF
Printer drivers included
Raster driver for Windows and macOS
Printing path
Print Anywhere with HP Smart app, HP Click, HP driver for macOS, HP driver for Windows, printing support for Chrome OS, email printing, HP Print Service Plugin for Android, Apple AirPrint
Line accuracy
±0.1%[3]
Theoretical minimum line width
0.02 mm
Model size
914 mm
PRINT SPEED
Print speed
30 sec/page on A1, 76 A1 prints per hour[1]
PRINTING MEDIA HANDLING
Finished output handling
Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
PRINT AREA
Non-printable area (cut-sheet)
5 x 5 x 5 x 5 mm
Non-printable area (roll media)
5 x 5 x 5 x 5 mm
PRINT RESOLUTION
Print quality color (best)
Up to 2400 x 1200 optimised dpi
Maximum optical density (black)
8 L* min/2.10 D[4]
PRINTING MEDIA
Media sizes standard (metric rolls)
279 to 914 mm
Roll external diameter
100 mm
Roll maximum input
1
Roll maximum weight
6.2 kg
Media thickness
Up to 11.8 mil
Supported Primary Applications
Line drawings
Presentations
Renderings
Recommended media
Q1396A HP Universal Bond Paper (FSC® certified)[5] (recyclable)[6] 610 mm x 45.7 m
C6019B HP Coated Paper (FSC® certified)[5] (recyclable)[6] 610 mm x 45.7 m
C6029C HP Heavyweight Coated Paper (FSC® certified)[5] (recyclable)[6] 610 mm x 30.5 m
SUPPORTED PRINTING MEDIA
Media sizes supported
Auto sheet feeder: A4, A3
manual feed: A4, A3, A2, A1, A0
Media sizes, custom
Auto sheet feeder: 210 x 279 to 330 x 482 mm
manual feed: 210 x 279 to 914 x 1897 mm
Media types
Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene)
Media weight, recommended
60 to 280 g/m² (roll/manual feed)
60 to 220 g/m² (auto sheet feeder)
Media width, maximum
914 mm
Media thickness (metric)
Up to 0.3 mm
