| Model |
HLD-100+ |
| Production Country |
China |
| Size (L x W x H cm) |
12 x 3 x 5 |
| Weight (kg) |
0.4 |
| Certifications |
Eco Friendly |
| Color |
blue |
| Main Material |
ABS |
| From the Manufacturer |
N/A |
| Care Label |
N/A |
Description:
- The HLD-100+ is the most reliable negative coronaShalogen leak detector at present.- We integrate all our experience and customera€™s feedback into this product in hope that it could provide our customer the best price performance and reliability. - The sensitive elements adopt the advanced and reliable coronaS refrigerant sensor - which has great sensitivity and excellent repeatability; The test program - is controlled by the artificial intelligent microcomputer, with reasonable work procedure, easy and convenient to operate, complete functions and multiple self-adaptive capabilities; Dual-color LED indicator light, with visual and clear display; smart and portable design is convenient for your mobile operation. when there is excessive refrigerant in the leak gas, this unit will automatically audio alarmed to effectively test the refrigerant leak.
Technical features:- Adopt advanced, low power consumed, eight-bit microprocessor controller - Dual-color LED indicator light with progressive and real time display- Sensitivity adjustable, seven level alarming indicated by LED display- Modular sensor, convenient for maintenance- Seven levels audible and visual alarm- Auto reset testing when the detector is turned on- Battery level indication
Technical parameters:- Sensor type: negative coronaS sensor- Ultimate sensitivity: 3 g/yr - Warm-Up Time: 3 Application:- Detect leaks in other systems and filling vessels. It will respond to all halogenated (including Chlorine and Fluorine) refrigerants. This includes, but is not limited to:CFCs : R12, R11, R500, R503etc. HCFCs : R22, R123, R124, R502etc. HFCs : R410a,R134a, R404a, R125 etc. - Mixtures such as AZ-50.HP62.MP39 etca€|- Detect Ethylene Oxide gas leaks in hospital sterilizing equipment- Detect SF-6 in high voltage circuit breakers - Detect most gases that contain chlorine, Fluorine and Bromine (halogen gases)- Detect cleaning agents used in dry cleaning applications such as perchloroethylene.
- Operating Environment:- Temperature: 0A°C i.550 A°C- Humidity: i¼oe95% RH (non-condensing)- Power supply: two 2# Alkaline Batteries (batteries not include in shipping for safety reason)- Sensor tip life under continuous operation: more than 50 hours in normal detecting status- Specification:230 x 60 x 55 (mm)- Probe length:36mm
Key Features
Adopt advanced, low power consumed, eight-bit microprocessor controller
Dual-color LED indicator light with progressive and real time display
Sensitivity adjustable, seven level alarming indicated by LED display
Modular sensor, convenient for maintenance
Seven levels audible and visual alarm
Auto reset testing when the detector is turned on
Battery level indication
What's In the Box
1*Gas Leak Detector
