Description
Body:Brass
Shutter:PPO
Springs:Stainless steel
Seals:Silicon Rubber
Temperature setting range:35-55 oC
Hot water inlet temperature range:Below 95
Cold water inlet temperature range:4-29 oC
Maximum working temperature:≤99 oC
Temperature stability:+/-2 oC
Hydrostatic :10bar
working (dynamic):5bar
Working :0.03-1Mpa
Ideal working :0.1-0.5Mpa
Connections: BSP,3/4", Inlets: M, Outlet: M
Flow rate(1 kg drop):26.67 L/min
One way valves:Tow inlets have one way valves
Features:
1、 Fail-safe on Hot or Cold Supply Failure
2、 Delivers Stable Mixed Water Temperature
3、Extended Mix Temperature Range : 35-55oC
4、Idea for Domestic and Public Water Application
5、Tamper-Proof Cap
What is the thermostatic mixing valve?
A Thermostatic Mixing Valve is a valve that blends hot water (stored at temperatures high enough to kill bacteria) with cold water to ensure constant, safe outlet temperatures preventing scalding.They shut-off rapidly in the event of a hot or cold supply failure to prevent scalding or thermal shock.TMVs accurately control water temperatures for bathing, showering and hand-washing. They maintain pre-set temperatures - even if water varies when appliances are used. TMVs can be fitted under baths and basins, be part of shower fittings, or as a feature of exposed hot and cold water mixers.
Installation Precaution:
1、All installations should be carried out by a Licensed Professional.
2、Install in accordance with markings on valve body. i.e. hot water inlet-marked H, cold water inlet-marked .
3、After temperature setting, if inlets temperature or fluctuates, outlet temperature variation is within +/-2 .
4、The external check valves at inlets prevent cross-flow of hotcold water when inlets is not the same.
5、If the ratio between two inlets is too large, one flow-limiting valve should be fixed at the side of higher .
6、Prior to installation, provisions should be made to flush the piping of any debris or foreign materials to ensure proper system operation.
a a a a a
Key Features
Reasonable price
Durable and practical
Top Sales Item
Shutter:PPO
Body:Brass
Seals:Silicon Rubber
Hydrostatic :10bar
Idea for Domestic and Public Water Application
Easy to use
Exquisite Workmanship
Well Made
Best Choice and best discounts
Customer Care is Our Top Priority
Offer is Subject to Availability
Big Sale
What's In the Box
1 x mixing valve
