120m HDMI Matrix Extender over IP is a device based on the standard TCP/IP protocol for transmitting HD audio and video source over LAN . It transmits your HD display with the high resolutions up to 120 meters away from your HDMI or DVI-D source by using one CAT5e/6 cable. At the same time, it’s also convenient to transmit HDMI audio and video source by point-to-point, multipoint-to-multipoint and cascade connection mode.
2.Features & Specifications
Support HDMI1.3/HDCP1.1&1.2
Support point-to-point mode, multipoint-to-multipoint mode and cascade connection mode.
Standard 802.3 Ethernet
Support one way IR extension.
Pure hardware design, plug and play, do not need to install additional software
3.Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) one piece of HDMI Infrared transmitter
2) one piece of HDMI Infrared receiver
3) Two pieces of DC 5V power supply
4) One pair of IR transmitter and receiver
5) User’s Manual
