CAT-5E/CAT-6 cable length between Rx and TX...up to 60m
High Resolution Input Thermometer... 4K/1080p/720p/576p/576i/480p/480i
Audio Format Support Audio Controller... DTS/Dolby/LPCM
High Resolution Output Thermometer......4K/1080p/720p/576p/576i/480p/480i
Max ventilator bandwidth.....600MHz
Max baud rate temperature controller...6Gbps x3
Temperature controller video signal input......0.5~1.5V pp
DC Controller DDC Signal Output.....5V pp(TTL)
HD cable input distance..............
HD cable output distance of the remote control.....
TX Max working current... 350mA
RX Max working current... 200 mA
Power adapter format Input device: AC (50Hz, 60Hz) 100V-240V; Output: DC5V/1A
Operating temperature range of thermometer.....(-15 to 55°C)
Operating Humidity Range Humidity Controller...... 5% to 90% RH (no condensation)
Dimension (L x W x H)
Package includes
1. Sensor transmitter...1pc
2. Receiver Receiver
3. Infrared cable
4.5V/1A Power Adapter... 2pcs
5. User manual for the controller
Connect and play
1. Connect the source device to the transmitter by one high-definition cable, the maximum cable length is 10 meters.
2. Connect the projector to the receiver by one HD cable, the maximum cable length is 10 meters.
3. Connect TX to RX by one cat5e or cat 6 (recommended), the max cable length is 60m.
4. One pair of IR RX and IR TX cable, connected to the 3.5mm IR RX and IR TX ports of the transceiver respectively.
5. Connect the power supply to TX and RX. 6. LED indicator:
6. When the HD indicator is on, it indicates that the HD signal input and the RJ45 indicator is on, indicating that the network port signal is input.
