Buy FRM01 DC 12V 1 Channel Multifunction Relay Module Loop Delay

FRM01 DC 12V 1 Channel Multifunction Relay Module Loop Delay Timer Switch

₦ 17,717.62 ₦ 18,650.13 -5%

0 No Reviews

Product SKU: RENG381749

Brand: Generic

Quantity

In Stock

100% Secure Payments

TrustPay

Pay Online Delivered T&C^*

Delivery Information

Shipped from overseas and normally delivered between 20-35 days

Have one to sell? Sell on rehmie

Product Specifications
Description

Model	N/A
Weight (kg)	0.029
Color	red
Main Material	Synthetic

Features:
Increase the supply anti-reverse function, and does not take the wrong power supply is damaged module.
The use of top-quality high-voltage power supply modules, discrete power supply before replacing the system more stable and reliable.
Increased 0.1 seconds timing, timing accuracy from the previous 0.1 seconds, upgrade to 0.01 seconds.
Increase automatic power saving feature, users can independently set.

Specifications:
Operating voltage: DC 12V.
Working current: 12V module is less than 50mA (relay action not less than 15mA, turn off the display less than 3mA).
Operating temperature: Recommended -30 ℃ -70 ℃ (the limits of -40 ℃ -80 ℃).
load capacity:
Normally open relay port maximum load capacity: DC 0-30V / 10A, AC 0-250V / 10A;
Relay NC port maximum load capacity: DC 0-28V / 10A, AC 0-125V / 10A.
Size: 66mm * 41mm * 20mm (L * W * H)

Package includes :
1 x Relay Module

Notes:
Due to the difference between different , the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures.
Please allow slight dimension difference due to different manual measurement.

Tips：Welcome to DreamyMarket. We will provide you the better service , the higher quality goods and the lower price. If you have any doubt about our product, please get contact with us, and we give you the answer as fast as possible.After you pay the bill, we promise you we will update the order to ready to ship.Once updated, we would ship the order in 24 hours,note that Saturdays are included in our time lines, during which our drop-off centers are operational. Before you sign the express ,please check up whether it has been broken. If you are satisfied with our product and our service, please give us the review of 5 stars as the recognition for our work.And you can add our shop in your collection so that once we have any pro motion or the thing you want is price down, we would sent an e-mail to inform you.If you are unsatisfied with us, please contact with us, we could give you the best solution.Hope you have a good experice in our shop!DreamyMarket is waiting for you!

Key Features

Increase the supply anti-reverse function, and does not take the wrong power supply is damaged module.
The use of top-quality high-voltage power supply modules, discrete power supply before replacing the system more stable and reliable.
Increased 0.1 seconds timing, timing accuracy from the previous 0.1 seconds, upgrade to 0.01 seconds.
Increase automatic power saving feature, users can independently set.
Operating voltage: DC 12V.

What's In the Box

1 X As described
