FEELWORLD F6S 5.0 inch IPS Screen Field MonitorFeatures1. High Resolution: Full HD 1920x1080
2. High Contrast: 1000:1
3. High Brightness: 450cd/square meter
4. 160 degree wide viewing angles IPS Panel
5. Provide auxiliary power out; allowing shooters to power their cameras
6. Histogram
7. Peaking Focus Assist (Red,Green,Blue three colors optional highlight over parts of the image in focus)
8. False Colors
9. Zebra Exposure
10. Nine Grid
11. Mode (Under , Over )
12. Zoom (4x,9x,16x)
13. Anamorphic Mode (1.3x, 2.0x, 2.0x mag, User-defined adjustment: 1.20X~2.00X)
14. Pixel to Pixel
15. Center Marker
16. Safe Area (80%, 85%, 90%, 93%, 96%, 2.35:1)
17. Ratio marker (4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1)
18. Marker Color (Red,Green,Blue,White,Black)
19. Check Field (Red/Green/Blue/Mono)
20. Image Flip (H, V, H/V)
21. Image Freeze
22. Zoom All (0~100 adjustable)
23. U/D & L/R Zoom (0~100 adjustable)
24. Color Temperature Adjustment
Specification1. Screen Size: 5 inch IPS
2. Resolution : 1920x1080 pixels
3. Pixel Pitch: 0.0571 (H) x 0.019 (W) mm
4. Aspect Ratio: 16:9
5. Brightness: 450cd/ square meter
6. Contrast Ratio: 1000:1
7. Backlight: LED
8. Viewing Angle: 80 degree /80 degree (L/R) 80 degree /80 degree (U/D)
9. Input: 1 x HDTV
10. Output: 1 x HDTV, 1 x DC port
11. Audio: Stereo Headphone
12. HDTV Input/ Output Support Format: 480i/576i/480p/576p, 1080i (60/59.94/50), 720p (60/59.94/50/30/29/25/24/23.98), 1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF), 4K UHD 3840x2160p (30/29.97/25/24/23.98Hz), 4096x2160p (24Hz)
13. Input Voltage: DC7 - 24V
14. Power Consumption: Less and equal 8W
15. Power Connector: DC
16. Working Temperature: -20 degree C~55 degree
17. Storage Temperature: -30 degree C~65 degree C
18. Install Way: 1/4 inch thread points
19. Unit Size: 136Lx75.7Hx25.2D (mm)
20. Uni
Key Features
FEELWORLD F6S 5.0 inch IPS Screen Field Monitor
FEELWORLD F6S 5.0 inch IPS Screen Field Monitor
FEELWORLD F6S 5.0 inch IPS Screen Field Monitor
FEELWORLD F6S 5.0 inch IPS Screen Field Monitor
FEELWORLD F6S 5.0 inch IPS Screen Field Monitor
What's In the Box
1 x package
