Features CGJ-100 For high-power shortwave radio stations using 5-100W
Mini short-wave automatic antenna tuner
TYPE-C charging interface M connector
With a 091-inch OLED display
This antenna tuner is automatically tuned and does not require any control wires suitable for most radio stations
Specifications
Power supply voltage USB charge and discharge
Maximum current consumption 400ma
Maximum working throughput 100W
Maximum possible measurement power 150W
Minimum power required to start tuning 5W
Minimum possible measurement power 01W
Measurement steps for power up to 10W 01W
Measurement steps for power higher than 10W 1W
Power measurement accuracy 10%
Maximum installation inductance 853uH
Minimum installation inductance step size 005uH
Maximum installation capacitance 1869pF
Minimum installation capacitance step 10pF
4pcs panel ons POW BYP AUTO and BOT function
Display 091inch OLED
Note
The device does not consider its own efficiency
Supply voltage is 5V standard voltage
Material Metal
colour black
Package Contents
1 x Automatic Antenna Tuner
Only the above package content other products are not included
Note Light reflection and different displays may cause the color of the item in the picture a little different from the real thing The measurement allowed error is - 1-3cm
What's In the Box
1 x Automatic Antenna Tuner
