System
Main processor Integrated processor
LINUX embedded operating system
Video and audio
Analog camera input 8 channels, BNC
HDCVI camera 1080P @ 25 / 30fps, 720P @ 25 / 30fps
AHD 1080P @ 25/30, 720P @ 25 / 30fps camera
TVI camera 1080P @ 25/30, 720P @ 25 / 30fps
CVBS PAL / NTSC camera
8CH: 8 + 2, each channel up to 5MP
Audio input / output 1/1, RCA
Two-way talk reuse audio input / output, RCA
Recording
H.264 video compression
Resolution 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Registration fee
Conventional:
QCIF (1 ~ 25 / 30fps)
8CH: the 1st channel 1080N / 720P (1 ~ 25 / 30fps), others
1080N (1 ~ 12fps) / 720P (1 ~ 15fps); 960H / D1 / HD1 / BCIF / CIF /
QCIF (1 ~ 25 / 30fps)
Sub esteram:
8 channels: CIF / QCIF (1 ~ 7 fps)
Video Bit Rate 32 Kbps ~ 4096 Kbps Per Channel
Recording mode Manual, schedule (general, continuous), MD (video detection:
Motion detection, video loss, tampering), alarm, shutdown
Recording interval 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Audio compression G.711A, G.711U, PCM
Audio sampling rate 8 KHz, 16 bits per channel
Audio bit rate 64 Kbps per
channel
Interface 1 HDMI, 1 VGA
Resolution 1920 × 1080, 1280 × 1024, 1280 × 720, 1024x768
Multi-screen display
When IP extension mode is not enabled:
8 channels: 1/4/8/9
When IP extension mode is enabled:
8 channels: 1/4/8/9/16
OSD camera title, time, video loss, camera lock, motion detection,
Recording
Network
Interface 1 RJ-45 port (100M)
Network function
HTTP, HTTPS, TCP / IP, IPv4 / IPv6, UPnP, RTSP, UDP, SMTP, NTP,
DHCP, DNS, IP Filter, DDNS, FTP,
Alarm Server, P2P, IP Lookup
(Supports Dahua IP Camera, DVR, NVS, etc.)
User Access 128 users
Smartphone iPhone, iPad, Android
ONVIF 16.12 interoperability, conforming to CGI
