| Production Country |
China |
| Size (L x W x H cm) |
Φ111.6x105mm |
| Weight (kg) |
0.64 |
| Color |
WHITE |
| Main Material |
PLASTIC |
| From the Manufacturer |
Long Distance Transmission Powered by leading HD Videoloss technology, it supports up to 500m/800m transmission over RG59/RG6 coaxial cables separately. Smart IR E series is designed with smart IR function to avoid IR LED over exposure when object/people is getting closer to the camera in the night, ensuring the light intensity is changing proportionally with the distance between camera and objects. Advanced 4-in-1 Technology E series is built in with advanced 4-in-1 technology, it's equipped with UTC chipset on board which could support to adjust HD analog signal output exibly, such as AHD/TVI/CVI/CVBS. It's the nal solution for true plug-n-play to work with any brand of HD analog DVR seamlessly. Protection With precise mechanical and rugged casing design, it stands against water and dust with industrial IP67 rank. Support ±30% input voltage tolerance, it could work safely in extreme unstable power condition. With working temperature range from -30°C to +60 °C, it works well in a variety of harsh outdoor environments. |
CameraOrdering Information1/2.8” 2MP Sony SensorTechnical ParametersDay/NightWhite BalanceNoise ReductionSupportedSupportedAuto(ICR)/ManualSupported2D/3D DNRBLCVideoVideo Output AHD/TVI/CVI/CVBSResolution 25/30fps@1080POSD Menu SupportedSupportedWDR DWDRLensFocal LengthAperture F1.4Motorized 2.8~12mm FOVGeneralWorking TemperatureWorking HumidityPower SupplyPower Consumption-30℃~+60℃10~90%DC12V±10%＜3.2W(IR cut o )Ingress ProtectionDimensionsNet WeightGross WeightIP67Φ111.6x105mm0.4KG0.64KGEective Pixels 1920(H)* 1080(V)Image SensorModelMin. IlluminationEL-32C28IEL-32C28I 2MP Analog Camera(2.8~12mm Lens)Scanning System ProgressiveS/N RatioIR DistanceIR LED NoMore than 52dB20~30m42°~107°2AGC
Key Features
1/2.8'' 1080P Starlight/WDR Sony Sensor
AHD/TVI/CVI/CVBS Video Output
IR Effective Range 20 ~ 30m
High Quality Motorized Lens 2.8 ~ 12mm
Lightning Protection Up to 6KV
IP67 Ingress Protection
What's In the Box
Long Distance Transmission
Powered by leading HD Videoloss technology, it supports up to 500m/800m transmission over RG59/RG6 coaxial cables separately.
Smart IR
E series is designed with smart IR function to avoid IR LED over exposure when object/people is getting closer to the camera in the night, ensuring the light intensity is changing proportionally with the distance between camera and objects.
Advanced 4-in-1 Technology
E series is built in with advanced 4-in-1 technology, it's equipped with UTC chipset on board which could support to adjust HD analog signal output flexibly, such as AHD/TVI/CVI/CVBS. It's the final solution for true plug-n-play to work with any brand of HD analog DVR seamlessly.
Protection
With precise mechanical and rugged casing design, it stands against water and dust with industrial IP67 rank.
Support ±30% input voltage tolerance, it could work safely in extreme unstable power condition.
With working temperature range from -30°C to +60 °C, it works well in a variety of harsh outdoor environments.
