Hikvision DS-2CE5AD0T-IP/ECO (3.6mm) 1MP (720P) Indoor Night Vision Dome Camera 1Pcs. Description: 2.0 Megapixel High-performance CMOS, Analog HD output, up to 1080P resolution, True Day/Night, Smart IR, Up to 20m IR distance, OSD Menu, Up the Coax (HIKVISION-C Protocol). Effective Pixels - 1296 (H) x 732 (V), Min. illumination- 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR. Signal System - PAL/NTSC. It comes with 12 LEDs and it has 2 wire cable (BNC and DC connection wire). It can be used with Hikvision HGHI, HQHI, HUHI & ECO Series Turbo HD DVR only for better and clear vision, Can Be Watched Online, High Quality Branded Product, Installation is not included. 2 Year Seller Warranty of Camera. (Physical Damage & Burning are not covering in Warranty). Before purchasing this product, please make sure that your DVR is supported to this camera.
The cameras has a clear resolution of
720P. it is compatible with other
1080P DVRS to improve its clarity. It has
smart IR vision of
20m during the night. It has motion detection, which can be configured in the dvr connected to alarm systems. the motion detection can also be used to minimize on the hard disk usage, there by saving space. For better clarity, the dvr should be connected to the monitor using HDMI cables. Uses less power; less than 1 ampere current and 12 volts dc power. It has automatic day and night switching. Its flat base makes it ideal for mounting on ceilings or flat surfaces. The outer cover prevents moisture from entering the camera, therefore can be mounted outdoors.
· 1.3 Megapixel high-performance CMOS
· Analog HD output, up to 720P resolution
· True Day/Night
· Up to 20m IR distance
With Smartphone and PC remote viewing
• H.264 /H.264+& Dual-stream video compression
• Support both HD-TVI /analog and AHD cameras with
adaptive access
• Full channel recording at up to 720P lite resolution
• HDMI and VGA output at up to 1920×720P resolution
• Long transmission distance over coax cable
• Support 720P resolution
Video InputVideo Compression: - H.264,H.264+
Analog and HD-TVI video input: - 4-ch BNC interface (1.0Vp-p, 75 Ω)
Support AHD input: 720P/25Hz, 720P/30Hz,
support CVBS input
Video Input Interface: - BNC (1.0 Vp-p, 75Ω)
HDMI/VGA Output: - 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Recording resolution: 720p/WD1/4CIF/VGA/CIF;
Frame Rate: - Main stream:
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Video Bit Rate: - 32 Kbps ~ 4 Mbps
Stream Type: - Video/Video&Audio
Audio Output: - 1-ch RCA(Linear, 1kΩ)
Dual Stream: - Support
Playback Resolution: -720p/WD1/4CIF/VGA/CIF
Network management
Remote connections: - 32
Network protocols: - TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
External Interface
Network Interface: - 1; 10M / 100M self-adaptive Ethernet interface
What's In the Box
x1 Hikvision 2MP Outdoor(Bullet) Camera
