18 Channel 9 Channel CCTV Security Camera Distribution Power Supply Box DC 12V 10A/15A/30A
Power supply panels for up to 18 cameras offer a more professional alternative to individual power adapters. Each outlet is individually fused and each panel is surge protected. LED light for monitoring the power status. Key lock prevents unauthorized access. Pro-size box provides plenty space for wires. It is divided into low voltage and high voltage space, to protect from high voltage damage to cameras.
Every channel is protected with Auto-Reset PTC fuses, which means these fuses will not blow.
This box can be mounted to any surface, plugged into an AC outlet, and up in seconds!
Dual Input Voltage: this power supply box converts AC110/220V to DC 12V.
Use it with For Security Cameras, DVR's etc
Power Box For electronic devices, like CCTV security cameras.CAN Support UP TO 18ch Cameras.
Individual LED indicator for each out put, every channel is protected with Auto-Reset fuses
✔ GOOD CONDITION - 100% Bran,d New and Quality Guarantee.
✔ Front mounted status LED ; Hinged lockable enclosure.
✔ Individually Fused Outputs Use For Security Camera
✔ Package Content: 1 x DC Power Connector Box, 1 Pack x Accessories, 2 x Keys, Power cable
Material: Iron
Channel: 18
Voltage: DC 12V
Electric Current: 10A
Color: Gray White
Size: 12.1 x 7.9 x 2inch (L x W x H)
Type: DC Power Connector Box
Use For: Security Camera
Install Place: Wall
Professional Power Supply.
Individually fused outputs.
Hinged lockable enclosure.
Front mounted status LED.
Safety cage protected transformer.
Package Content: 1 x DC Power Connector Box, 1 Pack x Accessories, 2 x Keys Power Plug
Key Features
✔ 12V DC regulated power box
✔ Input Voltage:AC110-120v AC220-240v
✔ 18 channel output
✔ Max. output 10Amp total
✔ Max. output 1Amp for each channel
✔ Support up 18,9,4 cameras, 9 individually outlet pairs
✔ Individual LED power indication, the red light shorts indicator helps you to know which camera is not working
✔ Main power switch with integral surge protection
✔ Metal case with lock prevents unauthorized access
✔ It offers a more professional alternative to individual power adapter
✔ DC 12V ~ 15 amp supply current
✔ Multiple outputs (Support up to18 cameras)
✔ Default 1A fuse
✔ Main power switch with surge protection
✔ Metal covered case with lock
✔ Individual LED status indicator
✔ For indoor use only
✔ Both type(1A+2A), numerous of fuse provided to fulfill any installation purpose.
Specifications 30Amp
✔ Output Voltage: DC 12V
✔ Output Port: 18 channel
✔ Output Power: 20-18w
✔ Max. Amp: 30A
✔ Fuse Type: Glass fuse
✔ Working Temperature: 0a„f~40a„f
✔ Storage Temperature: -20a„f~+85a„f
✔ Dimensions: (12.4 x 8.46 x 2.48)" / (31.5 x 21.5 x 6.3)cm (L x W x H)
What's In the Box
- Piece×12V 30A 18CH Power Supply Box
- AC Power Cord
- Piece×Key Lock
