Kingbolen K6 Pro All Car Diagnostic With Online ECU Coding And Tpms Programming
KINGBOLEN K6 PRO All System Car Diagnostic Tool 26+ Reset OBD2 Scanner TPMS ECU Coding DOIP CAN FD Battery Tester.
KINGBOLEN K6 PRO All System Diagnostic Tool 26+ Reset Function ECU CODING Active Test / Bi-directional Control TPMS Programming Battery Test Print CANFD DOIP FCA 2 Years Free Update
KINGBOLEN K6 PRO Supports ECU online Coding Function
Why does the car not work normally after replacing ECUs/ modules?
When an ECU/module is damaged, you have to replace a new one. After replacing the ECU/module, you have to follow the strict procedures of the manufacturer to match, learn, code, or even program it before it functions normally. Otherwise, the car cannot start or some parts cannot work normally.
What can KINBOLEN K6 PRO Scanner do?
Featuring ECU/Module replacement functions, KINGBOLEN K6 PRO Bi-directional Scanner can help you initialize, match, relearn, or code the newly replaced ECU/module to get it back on track.
ECU Coding: Customize Your Car in Minutes
* Same as other LAUNCH X431 High-end OE-level scan tool , KINGBOLEN K6 PRO has the capability of ECU coding to change preprogrammed options in the software, helping you customize your car faster as needed.
* Optimally code your car by changing some settings to fit your needs, such as setting alarms, doors locking, etc.
* Access the ECU to make full use of the hidden features or disable the car & rsquo;s annoying functions, like activating the auto side mirrors folding function, disabling the automatic engine Start-Stop function, etc.
* Provide excellent solutions for issues of drivability, power loss, fuel efficiency, etc. to improve the car & rsquo;s performance.
* Reprogram the adaptive data for certain components after repairs or replacements.
* ECU Online Coding is available for BMW, VW, Porsche, Renault, etc.
Please Note: ECU Coding changes preprogrammed options which depend on the type and number of electronic features already built in. Thus, ECU coding is not universally compatible and varies for different vehicles.
KINGBOLEN K6 PRO Supports Active Test & Bi-directional control
Bi-Directional Control capability and is capable of performing Active Tests to access vehicle-specific subsystems and component tests. The tester outputs commands to the ECU to drive the actuators in order to determine the integrity of the system or parts by reading the ECU data, or by monitoring the operation of the actuators .For example , KINGBOLEN K6 PRO have the ability to actuate relays, injectors, coils, or perform system tests, etc.
Also it will actuate solenoids valve and actuators for active testing to identify the error easily moreover. The bidirectional functions are quite extensive. even open an e.g.r. valve and seeing the difference in idle response and oxygen sensor voltage. Please note: Active tests are NOT universal for all vehicles, check compatibility with VIN number before purchase.
Active tests vary depending on the manufacturer, year, and model, and only the available tests display in the menu.
KINGBOLEN K6 PRO Supports TPMS Programming Function
1. Support Sensor Activation:
KINGBOLEN K6 PRO can activate all 315MHz/433MHz tire pressure sensors, and can read, copy, write sensor IDs and read tire pressure data (pressure, temperature, battery status)
2. Support Sensor Programming:
KINGBOLEN K6 PRO supports unlimited repeat programming function, covering more than 98% of imported models with tire pressure system, and supports multiple ID generation methods: manual, copy, and automatic creation.
3. Support Sensor Learning:
The tire pressure matching learning function can perform tire pressure fault diagnosis through prompt learning steps, including code reading and code clearing.
Pls Note :
KINGBOLEN K6 PRO supports LAUNCH sensor only !
KINGBOLEN K6 PRO supports Battery Test
1. it supports 6V,12V(Lead-acid battery, GEL battery and AGM battery)
2. Support common battery standards, such as CCA, DIN, JIS, EN, IEC, AH, SAE, BCI.
3. Support common battery types, such as ordinary battery (Regular Flooded), AMG start-stop battery (AGM Plate), GEL start-stop battery (GEL), EFP start-stop battery (EFP)
KINGBOLEN K6 PRO Supports Full System Diagnose Function
The Full Systems of the car mainly including Drive System, Chassis System, Body System, Electrical system :
1.PCM(Drive System): Engine, Transmission, Transfer case, Electrical Machine Electronics, Fuel Pump, Gear, and more...
2. Chassis System: Accumulator Management Electronics, Steering, Integrated Chassis Management, Tyre Pressure Control, Active Cruise Control, Braking System, Suspension, TPMS and more...
3.BCM(Body System): SRS Airbag, Camera, Audio Radio, Gateway, Cluster Dashboard, Rain Sensors, Charging Interface Module, Parking Assistance, Power Control Unit, Touch box, Light, Battery Charging System, Head up Display, Wipe Control System, Roof, Seat & Door Motor system, Immobilizer, ABS ESP system, Air Condition.Electric Windows, Telephone, and more...
4.Electrical System: Including Centralized control system for engine and power transmission, Chassis integrated control and safety system, Intelligent body electronic system, Communication and information / entertainment system.
It supports the detailed Function :
--read fault codes: read and decode the DTCs to identify where the fault location is;--clear fault codes: erase the DTCs to turn off the MIL after repairs;--retrieve ecu information: allows you to retrieve vehicle information;--Graph live data stream: view the dynamic data stream to determine vehicle condition--ECU Coding : Match, learn, or code the new ECU; Customize your car, unfold the hidden features, or disable the annoying functions; Reprograms the adaptive data for certain components after repairs.--Active Test ( Bi-directionnal Control ) : Actuate solenoids and actuators for active testing, send commands to systems/components to test their working status, without using the vehicle controls.
With the Diagnose Function , you can enhance performance, save energy, reduce emissions and more as following:
For Engine: detect common issues as Poor lubrication, Failing oil pump, Oil deposits and debris, Inadequate fuel and air compression, Leaking engine coolant, Blocked engine radiators, Prolonged engine detonation, Damaged oxygen sensors, Aged spark plugs, etc.
For SRS: pinpoint the trouble area as: a bad seat belt, a corroded crash sensor, or some water intrusion in a connector, etc.
For ABS: diagnose Blown sensor fuse, Low brake fluids, and Faulty sensor, etc.
For Transmission: avoid Grinding or shaking sensation in gear, Whining, humming or clunking noises, Burning smells, Gears Slipping, Low or Leaking Transmission Fluid, etc.
For TPMS: verify problems of Low tire pressure, Faulty in tire pressure monitor control module, Unknown tire sensor, Failure to identify tire sensor, etc.
KINGBOLEN K6 PRO supports 26+ Kinds of Special Reset Service Functions
( pls note different reset function supports different cars , also supports some cars , not for all cars , pls contact us check the detailed car list )
1 Oil Reset Service
This function enables you to reset the oil service for the engine oil life system,which calculates an optimal oil life change interval depending on the vehicle driving conditions and weather events.lt needs to be performed in the following cases:
A. lf the service lamp is on, run car diagnostics first for troubleshooting.Afterthat, reset the driving mileage or driving time, so as to turn off the servicelamp and enable a new driving cycle.
B. lf the service lamp is not on, but you have changed the engine oil or electricappliances that monitor oil life, you need to reset the service lamp.
2 Electronic Parking Brake Reset
This function enables you to reset the brake pad after replacing the brake pad.lt needs to be performed in the following cases:1.The brake pad and brake pad wear sensor are replaced.2.The brake pad indicator lamp is on.3.The brake pad sensor circuit is short, which is recovered.4.The servo motor is replaced.
3 Steering Angle Calibration
This function enables you to reset the steering angle,after replacing thesteering angle position sensor,replacing steering mechanical parts (such assteering gearbox,steering column, end tie rod, steering knuckie), performingfour-wheel alignment, or recovering car body.To reset the steering angle, first find the relative zero point position for thecar to drive in straight line. Taking this position as reference,the ECU cancalculate the accurate angle for left and right steering.
4 ABS Bleeding
This function allows you to perform various bi-directional tests to check theoperating conditions of Anti-lock Braking System(ABS).lt needs to be performed in the following cases:1. When the ABS contains air.2. When the ABS computer, ABS pump, brake master cylinder, brake cylinder,brake line, or brake fluid is replaced.
5 Gear Learning
This function enables you to perform tooth learning for the car, to turn off the MIL.lt needs to be performed in the following cases:1. After the engine ECu, crankshaft position sensor, or crankshaft flywheel isreplaced.2. The DTC 'tooth not learned' is present.
6 IMMo Service
This function enables you to perform the anti-theft key matching function, sothat the immobilizer control system on the car identifies and authorizes remotecontrol keys to normally use the car.lt needs to be performed in the following cases:When the ignition switch key, ignition switch,combined instrument panel,ECU,BCM, or remote control battery is replaced.
7 Injector Coding
This function enables you to write injector actual code or rewrite code inthe ECU to the injector code of the corresponding cylinder,so as to moreaccurately control or correct cylinder injection quantity.lt needs to be performed in the following cases:After the ECu or injector is replaced.
8 Battery Maintenance System Reset
This function enables you to perform a resetting operation on the monitoringunit of vehicle battery, in which the original low battery fault information will becleared and battery matching will be done.lt needs to be performed in the following cases:1. The main battery is replaced.2. The battery monitoring sensor is replaced.
9 Diesel Particulate Filter (DPF) Regeneration
This function enables you to clear PM(Particulate Matter) from the DPF filterthrough continuous combustion oxidation mode (such as high temperatureheating combustion,fuel additive or catalyst reduce PM ignition combustion)to stabilize the filter performance.lt needs to be performed in the following cases:1. The exhaust back pressure sensor is replaced.2. The PM trap is removed or replaced.3. The fuel additive nozzle is removed or replaced.4. The catalytic oxidizer is removed or replaced.5. The DPF regeneration MlL is on and maintenance is performed.6. The DPF regeneration control module is replaced.
10 Electronic Throttle Position Reset
This function enables you to make initial settings to throttle actuators andreturns the learned values stored on ECU to the default state. Doing so canaccurately control the actions of regulating throttle (or idle engine) to adjust theamount of air intake.
11 Gearbox Matching
This function enables you to complete the gearbox self-learming to improvegear shifting quality.lt needs to be performed in the following cases:When the gearbox is disassembled or repaired.
12 AFS (Adaptive Front-lighting System) Reset
This function enables you to initialize the adaptive headlamp system.
13 Sunroof Initialization
This function enables you to set the sunroof lock off,closed when it rains,sliding / tilting sunroof memory function, temperature threshold outside the caretc.
14 Suspension Calibration
This function enables you to adjust the height of the body.lt needs to be performed in the following cases:1. When replacing the body height sensor, or control module in the airsuspension system.2. When the vehicle height is incorrect.
15 EGR Adaption
This function is used to learn the EGR(Exhaust Gas Recirculation) valve afterit is cleaned or replaced.
16 Seats Calibration
This function is applied to match the seats with memory function that arereplaced and repaired.
17 Tyre Reset
This function is used to set the size parameters of the modified or replacedtire.
18 Coolant Bleed
Use this function to activate the electronic water pump before venting thecooling system.
19 AdBlue Reset (Diesel Engine Exhaust Gas Filter)
After the diesel exhaust treatment fluid (car urea) is replaced or filled up, ureareset operation is required.
20 NOx Sensor Reset
NOx sensor is a sensor used to detect the content of nitrogen oxides (NOx) inengine exhaust. lf the NOx fault is re-initialized and the NOx catalytic converteris replaced, it is necessary to reset the catalytic converter learned value storedin the engine ECu.
21 Windows Calibration
This function is used to perform door window matching to recover the ECuinitial memory, and recover the automatic ascending and descending functionof power window.
22 Language Change
This function is used to change system language of vehicle center console.
23 AF Reset
This function is applied to set or learn airlfuel rate parameters.
24 Transport Mode
To lower vehicle power consumption, user may perform the following operations: limit vehicle speed, not wake up the network for door open anddisable remote key etc. In this case, deactivating transport mode is needed torecover vehicle being normal.
25 StoplStart Reset
This function is used to open or close the automatic StartStop function viasetting the hidden function in ECU (The precondition is vehicle equipped withhidden function and hardware support).
26 TPMS Reset
After the tire pressure MIL turns on and maintenance is performed, the tire pressure resetting functionmust be performed to reset tire pressure and turn off the tire pressure MIL.Tire pressure resetting mustbe performed after maintenance is performed in the following cases: tire pressure is too low, tire leaks, tirepressure monitoring device is replaced or installed, tire is replaced, tire pressure sensor is damaged,andtire is replaced for the car with tire pressure monitoring function.
KINGBOLEN K6 PRO Supports Print Function
KINGBOLEN K6 PRO is with printer design , it can print the diagnose report directly .
it is thermal printing .
The print paper is with 57mm Width and 30mm diameter
KINGBOLEN K6 PRO Other Function
1. Auto VIN Scan 2. Data Record & Playback3. Diagnostic Report 4. DTC Lookup5. Online Feedback 6. Remote Diagnose
KINGBOLEN K6 PRO Supports Car List
Amercian Cars :
For BUICK, For CADILLAC, For CHEVROLET, For CHRYSLER, For DODGE, For FIAT(BRAZIL), For FORD, For FORD(AUSTRALIA), For GM, For GMBRAZIL), For JEEP, For LINCOLN
Europe Cars :
For ABARTH, For ALFA ROMEO, For ALFA ROMEO, For AUDI, For BENTLEY, For BMW, For BUGATTI, For CITROEN, For DACIA, For DR, For FORD (EUROPE), For FERRARI, For FIAT, For GAZ, For OPEL, For IVECO, For IZH, For JAGUAR, For LAMBORGHINI, For LANCIA, For LAND ROVER, For MASERATI, For MAYBACH, For MERCEDES-BENZ, For MINI, For OPEL, For PAZ, For PEUGEOT, For PORSCHE, For RENAULT, For ROLLS ROYCE, For ROVER, For SAAB, For SEAT, For SEAZ, For SKODA, For SMART, For SPRINTER, For UAZ, For VAUXHALL, For VAZ, For VOLVO, For VW, For VW_CV, For ZAZ
Asia Cars :
For ACURA, For DAEWOO, For DAIHATSU, For HOLDEN(AUSTRALIA), For HONDA, For HYUNDAI, For IKCO, For INFINITI, For ISUZU, For KIA, For LEXUS, For LUXGEN, For MAHINDRA, For MAHINDRA(INDIAN), For UNITEDPAKISTAN, For MARUTI, For MARUTI(INDIAN), For MAZDA, For MITSUBISHI, For MVM, For NISSAN, For GTR(NISSAN), For PERODUA, For PERODUA(MALAYSIA), For PROTON, For PROTON(MALAYSIA), For RENAULTSAMSUNG, For SAIPA, For SSANGYONG, For SUBARU, For SUZUKI, For TATA, For TATA(INDIAN), For ISuzu(THAILAND), For TOYOTA
China Cars :
For SENOUABAIC), For WEIWANGBAIC), For BJEV, For BAIC, For BRILLIANCE, For BYD, For CHANGAN, For CHANGHE, For BUICK(CHINA), For CHERY, For CHANGHESUZUKI, For DFCITROEN, For FENGGUANG(DONGFENG), For ECUAID, For FAW(TIANJIN), For FOTON, For JINLONG, For GONOW, For GWM, For HAFEI, For HAIMA, For JAC, For JAC REFINE, For SHINERAY, For JMC, For JOYLONG, For LIFAN, For MG(SAIC), For MAXUS, For SGM, For SOUEAST, For SPARK, For TRUMPCHI, For SGMW, For DFSK, For XINKAI, For POLARSUN, For ZX AUTO, For ZOTYE
KINGBOLEN K6 PRO Technical Specifications
Operating system: Android 10.0Memory: 4GBStorage: 64GBDisplay screen: 5.99-inch, LCD screenResolution: 1440 * 720Wi Fi: 2.4GHz, 5GHzBattery: 4500mAh, 7.6V
KINGBOLEN K6 PRO Packing List
1 * KINGBOLEN K6 PRO Main Unit 1 * OBDII Diagnostic Cable 1 * Battery Clip Cable1 * Power Adapter 1 * US Plug1 * UK Plug 1 * AU Plug 1 * Type C USB Cable 1 * For BENZ 38pin Connector1 * For BMW 20pin Connector 1 * For GM/VAZ 12pin Connector1 * For Chrysler 6pin Connector1 * For Toyota 17pin Connector1 * For Toyota 22pin Connector1 * For Kia 20pin Connector1 * For Honda 3pin Connector1 * For Nissan -14+16pin Cable 1 * For Fiat 3pin Cable1 * For M/H -12+16pin Cable 1 * OBD I extension Cable 1 * Cigarette Lighter 2 * Printer paper 1 * Password envelope1 * user manual 1 * Packing List
