Line interactive technology at an affordable price
• UPS is securing your data and your equipment by protecting you against power outages and bad power quality
• Work through under & overvoltage without wasting battery thanks to Automatic Voltage Regulation (AVR)
• Unmatched price/performance ratio
Eaton reliability
• Trust a leading manufacturer with decades of experience and high quality standards
• CE compliance certified by external agency (TUV)
• Rely on batteries anytime : 5E batteries are permanently recharged (even when off) and UPS can start without mains (Cold-start)
• Avoid back door damages coming through phone lines : 5E USB models are equipped with data line surge protection (Internet/Tel/Fax)
Easy integration
• Plug easily any equipment to the UPS (PC, HD TV, internet gateway,…) thanks to the IEC outlets
• Install 5E anywhere thanks to its small size
• Easily manage your UPS from your PC (on USB models):
• Automatic integration into Windows/MacOS/Linux power management for safe system shutdown
• Analyze energy use and costs, manage UPS parameters, with Eaton UPS Companion software
What is a Line-interactive UPS
• Line-interactive topology is used for protecting enterprise network and IT applications against power failure, power sag, power surge, under voltage and overvoltage. In normal mode, the device is controlled by a microprocessor that monitors the quality of the supply and reacts to fluctuations.
• A voltage compensation circuit is enabled to boost or reduce the supply voltage in order to compensate for fluctuations. The main advantage of line-interactive topology is that it enables compensation for under- and overvoltage without using the batteries.
Power Management Software
UPS Companion Software ideally suited for power management of personal computers (and their associated peripherals) with USB connection to the UPS.
Software is available as a free download from the Eaton website and USB cable must be purchased separately
Specifications
• Stock Code - 5E650IUSB
• Description Eaton 5E 650VA 360Watts Line Interactive USB UPS
• Device Type UPS - external
• Form Factor – Desktop Tower
• Rating (VA/W): 650VA/360W
•Topology Line Interactive with Automatic Voltage Regulation
• Input Voltage range without using batteries: 170V – 280V
• Output Voltage: 230V
• Data Line surge protection: Yes
• Input Connectors 1 x power IEC 320 EN 60320 C14 (10A)
• Output connectors 4 x power IEC 320 EN 60320 C13 (2x UPS and 2x Surge )
• Battery Backup time for 1 PC: 16 Minutes
• Battery Backup time for 2 PCs: 6 Minutes
• Battery Backup time for 3 PCs: – Not Possible
• Battery Backup time for 4 PCs: –Not Possible
• Communication Ports: 1 USB Port
• Operating Temperature: 0 to 40°
• Noise Level: <40dB
• Dimensions (DxHxW): 288mm x 148mm x 100mm
• Weight: 4.64Kg
Eaton UPS Companion software (available on
* Backup times are approximate and may vary with equipment, configuration, battery age, temperature, etc.
